DMR-XW380EBK vol.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
W241 ERJ8GEY0R00V 1/4W 0 1 C8702 F1G1A1040006 10V 0.1U 1
W242 ERJ3GEY0R00V 1/10W 0 1 C8703 F1G1A1040006 10V 0.1U 1
W243 ERJ8GEY0R00V 1/4W 0 1 C8704 F1G1A1040006 10V 0.1U 1
W244 ERJ6GEY0R00V 1/8W 0 1 C8705 F1G1A1040006 10V 0.1U 1
W245 ERJ3GEY0R00V 1/10W 0 1 C8706 F1G1A1040006 10V 0.1U 1
W246 ERJ6GEY0R00V 1/8W 0 1 C8707 F1H1C104A071 16V 0.1U 1
W247 ERJ3GEY0R00V 1/10W 0 1 C8708 F1G1A1040006 10V 0.1U 1
C8709 F1G1A1040006 10V 0.1U 1
ZJ3001 K9ZZ00001279 EARTH PLATE 1 C8710 F1G1A1040006 10V 0.1U 1
ZJ3002 K9ZZ00001279 EARTH PLATE 1 C8711 F1G1A1040006 10V 0.1U 1
C8712 F1G1A1040006 10V 0.1U 1
C8713 F1G1A1040006 10V 0.1U 1
C8714 F1G1A1040006 10V 0.1U 1
## VEP70352A FRONT (L) P.C.B. (RTL) E.S.D. C8715 F1H1H1000008 50V 10P 1
C8716 F1H1H1000008 50V 10P 1
P7001 K1KA03AA0301 CONNECTOR(3P) 1 C8717 F1H1C104A071 16V 0.1U 1
C8718 F1G1A1040006 10V 0.1U 1
S7002 EVQ11A05R TOUCH SWITCH 1 C8719 F1G1A1040006 10V 0.1U 1
C8720 F1G1A1040006 10V 0.1U 1
C8723 F1H1A105A028 10V 1U 1
C8724 F1J0J106A014 6.3V 10U 1
## VEP70354A FRONT (R) P.C.B. (RTL) E.S.D. C8725 F1G1A1040006 10V 0.1U 1
C8726 F1H1H1000008 50V 10P 1
C7202 F1H1A105A028 10V 1U 1 C8727 F1H1H1000008 50V 10P 1
C7203 F1H1C104A071 16V 0.1U 1 C8728 F1H1C104A071 16V 0.1U 1
C7204 F1H1H103A219 50V 0.01U 1 C8729 F1G1A1040006 10V 0.1U 1
C7205 F1H1C104A071 16V 0.1U 1 C8730 F1G1A1040006 10V 0.1U 1
C8731 F1G1A1040006 10V 0.1U 1
D7201 B3AAA0001018 LED 1 E.S.D. C8732 F1G1A1040006 10V 0.1U 1
D7202 B3AAA0001018 LED 1 E.S.D. C8733 F1H1C104A071 16V 0.1U 1
C8734 F1G1A1040006 10V 0.1U 1
DP7201 A2BD00000199 FL DISPLAY 1 C8735 F1G1A1040006 10V 0.1U 1
C8736 F1G1A1040006 10V 0.1U 1
IC7201 C0HBB0000061 IC 1 E.S.D. C8737 F1G1A1040006 10V 0.1U 1
C8738 F1G1A1040006 10V 0.1U 1
IR7201 PNA4861M02VT REMOTE SENSOR 1 C8739 F1G1A1040006 10V 0.1U 1
C8740 F1G1A1040006 10V 0.1U 1
LB7201 J0JCC0000103 COIL 1 C8741 F1G1A1040006 10V 0.1U 1
LB7202 J0JCC0000103 COIL 1 C8742 F1G1A1040006 10V 0.1U 1
C8743 F1G1A1040006 10V 0.1U 1
P7201 K1KA03AA0301 CONNECTOR(3P) 1 C8744 F1G1A1040006 10V 0.1U 1
P7202 K1KA12B00136 CONNECTOR(12P) 1 C8747 F1G1C1030008 16V 0.01U 1
C8748 F1H1A105A028 10V 1U 1
Q7201 B1ABDF000026 TRANSISTOR 1 E.S.D. C8749 F1J0J106A020 6.3V 10U 1
C8750 F1H1A105A028 10V 1U 1
QR7201 B1GBCFEN0015 TRANSISTOR 1 E.S.D. C8753 F1J0J106A020 6.3V 10U 1
QR7202 B1GBCFEN0015 TRANSISTOR 1 E.S.D. C8754 F1J0J106A020 6.3V 10U 1
C8755 F1H1A105A028 10V 1U 1
R7201 ERJ3GEYJ330V 1/10W 33 1 C8756 F1H1H8R0A016 50V 8P 1
R7202 ERJ6GEYJ820V 1/8W 82 1 C8757 F1H1H8R0A016 50V 8P 1
R7206 ERJ6GEYJ820V 1/8W 82 1 C8758 F1H1H3300005 50V 33P 1
R7208 ERJ3GEYJ683V 1/10W 68K 1 C8759 F1H1H103A219 50V 0.01U 1
R7209 ERJ3GEYJ101V 1/10W 100 1 C8762 F1H1H103A219 50V 0.01U 1
R7210 ERJ3GEYJ101V 1/10W 100 1 C8763 F1H1A105A028 10V 1U 1
R7211 ERJ3GEYJ101V 1/10W 100 1 C8764 F1H1A105A028 10V 1U 1
R7212 ERJ3GEYJ104V 1/10W 100K 1 C8765 F1G1C1030008 16V 0.01U 1
C8766 F1H1H103A219 50V 0.01U 1
S7201 EVQ11A05R TOUCH SWITCH 1 C8767 F1H1A105A028 10V 1U 1
C8768 F1H1A105A028 10V 1U 1
W50 ERJ6GEY0R00V 1/8W 0 1 C8774 F1J0J106A014 6.3V 10U 1
W51 ERJ6GEY0R00V 1/8W 0 1 C8778 F1G1H2200001 50V 22P 1
W52 ERJ6GEY0R00V 1/8W 0 1 C8779 F1G1H2200001 50V 22P 1
W53 ERJ6GEY0R00V 1/8W 0 1 C8780 F1G1H2200001 50V 22P 1
W54 ERJ6GEY0R00V 1/8W 0 1 C8781 F1G1H2200001 50V 22P 1
W55 ERJ6GEY0R00V 1/8W 0 1 C8782 F1G1H2200001 50V 22P 1
W56 ERJ6GEY0R00V 1/8W 0 1 C8783 F1G1H2200001 50V 22P 1
W57 ERJ3GEY0R00V 1/10W 0 1 C8784 F1J0J106A020 6.3V 10U 1
W58 ERJ6GEY0R00V 1/8W 0 1 C8785 F1H1A105A028 10V 1U 1
W59 ERJ3GEY0R00V 1/10W 0 1 C8786 F1H1H8R0A016 50V 8P 1
C8787 F1H1H8R0A016 50V 8P 1
ZB7201 RMN0946-1 FL HOLDER 1 C8788 F1H1H3300005 50V 33P 1
C8789 F1H1H103A219 50V 0.01U 1
C8792 F1G1H2200001 50V 22P 1
C8793 F1G1H2200001 50V 22P 1
## VEP77159A TUNER PACK P.C.B. (RTL) E.S.D. C8796 F1H1C104A071 16V 0.1U 1
C8797 F1H1C104A071 16V 0.1U 1
C8701 F1G1A1040006 10V 0.1U 1 C8798 F1G1A1040006 10V 0.1U 1
S-49
