LED5 PNL LED Control Signal
LED6 PNL LED Control Signal
LED7 PNL LED Control Signal
LED8 PNL LED Control Signal
LED9 PNL LED Control Signal
LEDCT0 PNL LED Control Signal
LEDCT1 PNL LED Control Signal
LEDCT2 PNL LED Control Signal
LEDCT3 PNL LED Control Signal
LEDCT4 PNL LED Control Signal
MODE-SW Scan Mode Select Signal
N.C. No Connection
n5VMTON Monitor ON / OFF Select Signal
NA 2nd Feeder Motor Control Signal
nADUST LSU APC Timing
nAPNT ADF Paper Detection Sensor Signal
NB 2nd Feeder Motor Control Signal
nBECOE Read Control Signal
nBOOK ADF Open / Close Detection Signal
NCBSY Busy Command
nCHGCTL HVPS Charge Control (ON/OFF)
nCSMON Modem Chip Select Signal
nDB Developer (+ Voltage PWM Pulse)
nDBCH Developer Charge (+/- Change)
nEBCWBE[0] Write Control Signal
nEXITSEN EXIT Sensor Signal
nFCTL Fuser ON/OFF Control
nFXBSET FXB Detection Signal
nFXBWUP Wake Up Signal
nHKOF5V Off-Hook Detection Signal
nHSYNC Horizontal Sync Signal
nLDON LD Light Enable
nLEDACT ACTIVE Lamp LED Control Signal
nLEDALM ALARM Lamp LED Control Signal
nLEDAT DATA Lamp LED Control Signal
nLEDSLP Energy Saver Lamp LED Control Signal
nLPOW1 +5 VDC Power Supply Return Signal
nMDMINT Modem Interruption Signal
nMDMRST Modem Reset Signal
nMMCTL Main Motor Control Signal
nMMHALF Motor Rotation Speed Control
nMMLD Main Motor Rotation Signal
nMOEN_OP 2nd Feeder Motor Control Signal
nMPOW1 Power Supply Control Signal
nMVOL0 Monitor Volume Control Signal
nMVOL1 Monitor Volume Control Signal
Glossary of Electrical Abbreviations
Signal Name Function
