WR902 FP-X0
Address
Name
Description
R9020 RUN mode flag
Turns off while the mode selector is set to PROG.
Turns on while the mode selector is set to RUN.
R9021
Not used
-
R9022
Not used
-
R9023
Not used
-
R9024
Not used
-
R9025
Not used
-
R9026
Message flag
Turns on while the F149 (MSG) instruction is executed.
R9027
Not used
-
R9028
Not used
-
R9029 Forcing flag
Turns on during forced on/off operation for input/output
relay timer/counter contacts.
R902A Interrupt enable flag
Turns on while the external interrupt trigger is enabled by
the ICTL instruction.
R902B
Interrupt error flag
Turns on when an interrupt error occurs.
R902C Sample point flag
Sampling by the instruction=0
Sampling at constant time intervals=1
R902D Sample trace end flag
When the sampling operation stops=1,
When the sampling operation starts=0
R902E
Sampling stop trigger
flag
When the sampling stop trigger activates=1
When the sampling stop trigger stops=0
R902F Sampling enable flag
When sampling starts=1
When sampling stops=0
