Panasonic FP7 Series Additional Functions Manual

Table of Contents
ii
Table of Contents
1. Introduction of Ver.4.20 ..................................................... 1-1
1.1 Introduction of FP7 CPU Unit Ver.4.20 .................................................. 1-2
2. Basic Instructions .............................................................. 2-1
2.1 List of Instructions.................................................................................. 2-2
2.2 TM16 (16-bit Timer) ............................................................................... 2-3
2.3 CT16- (16-bit Counter) .......................................................................... 2-6
2.4 Precautions for Programming ................................................................ 2-9
3. High-level Instructions ...................................................... 3-1
3.1 List of Instructions.................................................................................. 3-2
3.2 BKEXT (16-bit Data Sign-extended Block Move) ................................... 3-3
3.3 BKMV16 (Block Move (32-bit Data to 16-bit Data)) ................................ 3-5
3.4 DIVFP2 (Division (FP2 Compatible)) ..................................................... 3-7
3.5 BTS (16-bit Data Specified Bit Set) ........................................................ 3-9
3.6 BTR (16-bit Data Specified Bit Reset) .................................................. 3-11
4. FP2/FP2SH Program Conversion Function ...................... 4-1
4.1 List of Conversion Instructions to FP7 ................................................... 4-2
4.2 Conversion of Special Relays ................................................................ 4-5
4.3 Conversion of Special Data Registers ................................................... 4-7
5. MEWTOCOL-COM .............................................................. 5-1
5.1 List of Commands.................................................................................. 5-2
6. Multi Connection Server Function .................................... 6-1
6.1 Multi Connection Server Function .......................................................... 6-2
6.1.1 Setting Conditions and Operating Conditions ......................................... 6-2
6.1.2 Precautions When Connecting Multi Connection Servers ...................... 6-4
6.2 How to Set Connections ........................................................................ 6-5
