7.6 Connecting the 5V Type to the TOOL Port of FP2/FP2SH
257
7.6 Connecting the 5V Type to the TOOL Port of
FP2/FP2SH
The 5V type is powered via the TOOL port cable.
Please read the cautions regarding the power supply before connecting (see p.
252).
Communication format settings
System register no.
Item
Value
410
TOOL port station number
1
411
Sending data length
8 Bits
411
Modem connection
No modem connection
414
TOOL port baud rate setting
9600 bps
For more information on the communication settings, please refer to the GT
Series User Manual.
