19
VQT3J95
23 Tripod receptacle
≥ If you attach a tripod which has a 5.5 mm
(0.22 q) screw or larger, it may damage
this unit.
24 Battery release lever [BATT] (l 20)
25 Photoshot button [ ] (l 33)
26 Zoom lever [W/T] (In Recording
Mode) (l 47)
Thumbnail display switch [ / ]/
Volume lever [sVOLr] (In Playback
Mode) (l 37)
27 Mode switch (l 27)
28 Status indicator (l 26)
29 DC input terminal [DC IN] (l 21)
≥ Do not use any other AC adaptors except
the supplied one.
30 Grip belt
Adjust the length of the grip belt so that it fits
your hand.
1 Flip the belt.
2 Adjust the length.
3 Replace the belt.
