Panasonic KX-FT21BX

- 173 -
KX-FT21LA
This replacement parts list is for the KX-FT21LA only.
Ref. No. Part No. Part Name & Description Pcs
Model KX-FT21LA
20 PFDG1123Z GEAR, PLATEN 1
Notes: 21 PFHG1064Z SEPARATION RUBBER 1
1. The marking (RTL) indicates that the Retention Time is limited f or this item. 22 PFDE1101Z LEVER, ADJUSTMENT 1
After the discontinuation of this assembly in production, the item will 23 PFUS1173Z SPRING, DOCUMENT FEED 1
continue to be av ailable f or a specif ic period of time. The retention period 24 PFHX1251Z READING SHEET 1
of availability is dependent on the ty pe of assembly , and in accordance 25 PFDJ1021Z PLATEN SPACER, R 1
with the laws gov erning part and product retention. Af ter the end of this 26 PFBX1080Z1 KEY, FUNCTION S 1
period, the assembly will no longer be av ailable. 27 PFBX1079Z1 KEY, 10 S 1
2. Important safety notice. 28 PFBC1041Z1 KEY, START S 1
Components identified by the mark special characteristics important
for safety.
When replacing any of these components, use only manuf acturer's specif ied
(2. UPPER CABINET/
parts.
THERMAL HEAD SECTION)
3. The S mark indicates service standard parts and may dif f er from production
parts. 50 PFKM1049Z1 HANDSET CRADLE S 1
4. RESISTORS & CAPACITORS 51 PFHR1132Z COVER, HEAD 1
Unless otherwise specif ied. 52 PFDE1098Z HEAD GUIDE, L 1
All resistors are in ohms (
Ω
) k=1000
Ω
, M=1000k
Ω
53 PFJHS017Z THERMAL HEAD 1
All capacitors are in MICRO FARADS(
µ
F ) P=
µµ
F 54 PFDE1099Z HEAD GUIDE, R 1
*Type &Wattage of Resistor 55 PFBH1011Z1 BUTTON, HOOK S 1
Type 56 PFJS11Q45Z CONNECTOR, 11PIN 1
ERC:Solid ERX:Metal Film PQRD:Carbon 57 PFDJ1018Z ROLLER HOLDER 2
ERD:Carbon ERG:Metal Oxide PQRQ:Fuse 58 PFDN1032Z ROLLER, DOCUMENT FEED 1
PQ4R:Chip ERO:Metal Film ERF:Wire Wound 59 PFDG1122Z GEAR, EXIT ROLLER 1
Wattage
10,16,18:1/8W 14,25,S2:1/4W 12,50,S1:1/2W 1:1W 2:2W 5:5W 60 PFQT1503Z CAUTION LABEL 1
61 PFUS1172Y SPRING, THERMAL HEAD 4
ECFD:Semi-Conductor ECCD,ECKD,PQCBC,PQVP : Ceramic 62 PFDE1102Z1 LEVER, LOCK S 1
ECQS:Styrol ECQM,ECQV,ECQE,ECQU,ECQB : Polyester 63 PFJS02Q42Z CONNECTOR, 2PIN 1
PQCBX,ECUV:Chip ECEA,ECSZ,ECOS : Electrolytic 64 PFAS50P003Z SPEAKER 1
ECMS:Mica ECQP : Poly propylene 65 PFUS1179Z SPRING, LOCK LEVER 1
Voltage 66 PFHE1019Z IMASEN FORM 2
ECQ Type ECQG ECSZ Type Others 67 PFUS1176Z SPRING, OPERATION COVER OPEN 1
ECQV Ty pe 68 PFKM1048X1 MAIN CABINET S 1
1H: 50V 05: 50V OF:3.15V OJ :6.3V 1V :35V 69 PFHX1268Y SHEET, IMASEN 1
2A:100V 1:100V 1A:10V 1A :10V 50,1H:50V
2E:250V 2:200V 1V:35V 1C :16V 1J :63V 70 PFUS1181Z SPRING, EARTH 1
2H:500V OJ:6.3V 1E,25:25V 2A :100V 71 PFDJ1013Y SPACER, ROLLER 1
72 PFDN1034Z ROLLER, SEPARATION 1
73 PQUS10055Z SPRING, ONE WAY S 1
Ref. No. Part No. Part Name & Description Pcs 74 PFDE1059Z SPACER 1
75 PFDG1124Z GEAR, SEPARATION ROLLER 1
CABINET AND ELECTRICAL PARTS 76 XUC2FY RETAINING RING 1
77 PF0U1018Z IMAGE SENSOR 1
(1.OPERATION PANEL SECTION)
78 PFJE1005Z LEAD, IMAGE SENSOR 1
79 PFGT1436Z-C NAME PLATE S 1
1 PFGP1140Z PANEL, LCD 1
2 PFGV1009Z COVER, TEL CARD 1 80 PFQT1186Y CAUTION LABEL 1
3 PFGD1043Z TEL CARD 1
4 PFBX1078Z1 KEY, DIAL S 1
5 PFKR1014Z1 DOCUMENT GUIDE, L S 1
6 PFUS1170 SPRING, DOCUMENT LEVER 1
7 PFGG1039Z1 OPERATION PANEL S 1
(3. LOWER SECTION)
8 PFKR1015Z1 DOCUMENT GUIDE, R S 1
9 PFDG1015Y GEAR, DOCUMENT GUIDE 1 100 PFMD1039Z FRAME, BOTTOM 1
101 PFHA1001Z LEG RUBBER 1
10 PFJE1007Z LEAD, OPERATION 1 102 PFJP03S04Z AC INLET 1
11 PFJE1006Z LEAD, OPERATION 1 103 PQLB1E1 FERRITE CORE 1
12 PFDE1096Z LEVER, DOCUMENT DETECTION 1 104 PQJS02Q59Y CONNECTOR, 2PIN 1
13 PFDE1100Z LEVER, READ DETECTION 1 105 XWC4B WASHER 1
14 PFUV1024Z COVER, OPERATION 1 106 PFUS1177Z SPRING, EARTH 1
15 PQDR9685Y ROLLER, SUPPORT 1 107 PFJS08R44Z CONNECTOR, 8PIN 1
16 PFUS1171Z SPRING, ROLLER 2 108 PFDE1097Z LEVER, PAPER SENSOR 1
17 PFDF1017Z SHAFT 1 109 PFUS1214Z SPRING, EARTH 1
18 PFDJ1020Z PLATEN SPACER, L 1
19 PFDN1033Z ROLLER, PLATEN 1
REPLACEMENT PARTS LIST
