Panasonic KX-FT21BX

KX-FT21LA
- 130 -
Document Exit
Roller
Separation Roller
SWITCH 3
MOTOR
Read Position
Sensor
Document Sensor
Recording Paper
Sensor
Platen Roller
Sensor Circuit
Location
Sensor
Sensor or Switch name
Digital
SW1
SW3
Cover Open and
Paper Set
PS2
Document
Read Position
• uCHECK COVER•vand
• uOUT OF PAPER• v
• uREMOVE DOCUMENT• v
Sensor Locations
MOTOR Position
4.6 SENSORS AND SWITCHES
All of the sensor and switches are shown below.
Analog
Operation Panel
SW2
Hook SW
-----
PS1
Document
• uCHECK DOCUMENT• v
-----
