Panasonic KX-TDA50

4.1 Troubleshooting
Installation Manual 137
Connection between the central office and the Hybrid IP-PBX:
CAUSE
CO line is connected to the T2/T1.
CO line is connected to the T2/R1.
SOLUTION
Reconnect the CO line to
the T1/R1 or T2/R2 of the
telephone jack using
2-conductor wiring.
T2
R1
T1
R2
CO line Hybrid IP-PBX
Hybrid IP-PBX
CO line
T2
R1
T1
R2
(Continued from the
previous page.)
Can you dial
out on a
CO line?
No
