1.2 Basic System Construction
18 Installation Manual
1.2 Basic System Construction
1.2.1 Main Unit
The main unit is equipped with 4 analog trunk ports (one LCOT4 card) and 4 extension ports (Super Hybrid
Ports). For system expansion, optional service cards can be installed, and an additional AC adaptor can
also be connected.
Construction of Main Unit
Main Board
LCOT4 card
(installed by default)
Front Cover Cable Cover
To Next Page
