4.1 Troubleshooting
142 Installation Manual
5 Sub Code Five-digit sub code (1XXYY)
1: Cabinet number
XX: Slot number
00 to 11 (00: MPR; 01: Super Hybrid Ports; 02 to 11: Slots for
optional service cards)
YY: Physical port number (01 to 16)
For optional service cards that are installed in Slots 08 to 11, sub
slot number + port number will be displayed.
Sub slot 1: 11 to 14
Note
When there is no parameter for slot and physical port number, XX
and YY will be displayed as "00".
Example: Sub code for MPR = 10000
6 Error Message Error description
Item Description
