Panasonic KX-TDE100

Connection Example
This diagram shows you a connection example.
Doorphone & Door Opener
External Music Source
Pager/
Speaker
Batteries
Remote PC
PC
Printer
Telephone Company
PBX
Amplifier
External Sensor/
External Relay Device
KX-T7600 KX-T7600
Voice Processing
System
KX-T7636/
KX-T7633
Router
PC
CSPS
Wireless Phone
Fax Machine
PC
USB
APT
DPT
ISDN Telephone
CTI Server
PC
PC
SLT
DSS Console
DSS Console
IP-PT
IP Softphone
SIP Extension
Private
IP Network
ITSP
*
1
Network
DCE
*
2
(e.g., ADSL
Modem)
WAN
PC
USB
KX-DT300 KX-DT300
KX-DT346/
KX-DT343
*1
ITSP: Internet Telephony Service Provider
*2
DCE: Data Circuit Terminating Equipment
