1. Introduction
Lens
H-FS12032
1 3
5 6
2 4
1
Lens surface
2
Tele
3
Zoom ring (58)
4
Wide
5
Contact point
6
Lens fitting mark (33)
Tripod grip
1
9
5
3 4
6
7
2
8
1
Camera screw
2
Camera stand
3
Fastening knob
4
Hand strap eyelet
5
Video rec. button
6
Shutter button
7
Sleep button
8
Grip
9
Connection cable
• For information on how to attach the camera and operate the tripod grip, refer to
page 47.
