Panasonic LUMIX DMC-G7 User Manual

3. Recording Modes
100
Applicable modes:
The effects of aperture and shutter speed can be checked by using the Preview Mode.
•
Confirm the effects of aperture: You can check the depth of field (effective focus range)
before taking a picture by closing the leaf shutter to the aperture value you set.
• Confirm the effects of shutter speed: Movement can be confirmed by displaying the actual
picture that will be taken with that shutter speed.
When the shutter speed is set for high speed, display in the shutter speed preview will be
displayed like a time-release film. It is used in cases such as stopping the movement of running
water.
1 Set a function button to [Preview]. (P70)
•
The following step is an example in which [Preview] is assigned to [Fn4].
2 Switch to confirmation screen by pressing [Fn4].
•
Screen is switched every time [Fn4] is pressed.
Depth of field properties
¢1 Recording conditions
¢2 Example: When you want to take a picture with a blurred background etc.
¢
3 Example: When you want to take a picture with everything in focus including the background etc.
• It is possible to record while in Preview Mode.
• Range for shutter speed effect check is 8 seconds to 1/16000th of a second.
Not available in these cases:
•
Preview Mode is not available when recording with [ ] ([4K Pre-Burst]) of the 4K Photo
function.
Confirm the Effects of Aperture and Shutter Speed (Preview Mode)
Normal recording screen
Aperture effect preview
screen
Aperture effect: ±
Shutter speed effect: —
Shutter speed effect
preview screen
Aperture effect: ±
Shutter speed effect: ±
¢1
Aperture value Small Large
Focus length of the lens Tele Wide
Distance to the subject Near Distant
Depth of field (effective focus range) Shallow (Narrow)
¢2
Deep (Wide)
¢3
6KWU6SHHG(IIHFWDGGHG
Fn4
3UHYLHZFRPSOHWHG
Fn4

Panasonic LUMIX DMC-G7 Specifications

General

Megapixel	16.00 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	4592 x 3448, 3232 x 2424, 2272 x 1704, 1824 x 1368, 4592 x 3064, 3232 x 2160, 2272 x 1520, 1824 x 1216, 4592 x 2584, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3424 x 3424, 2416 x 2416, 1712 x 1712, 1712 x 1712
Filter size	52 mm
Optical zoom	- x
Focal length range	14 - 42 mm
Maximum aperture number	22
Minimum aperture number	3.5
Number of diaphragm blades	7
Number of aspheric elements	1
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/25 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Flash range (wide)	- m
Flash exposure correction	±3EV (1/2; 1/3 EV step)
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution	3840 x 2160 pixels
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Vari-angle LCD display	-
Display resolution (numeric)	1040000 pixels
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Children, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effects	Negative film, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
GPS (satellite)	No
Self-timer delay	2, 10 s
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	360 shots
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	77.4 mm
Width	124.9 mm
Height	86.2 mm
Weight	360 g
Weight (including battery)	410 g
