2. Getting Started/Basic Operations
80
If you set a different language by mistake, select [~] from the menu icons to set the desired
language.
This enables the firmware versions of the camera and lens to be checked.
Press [MENU/SET] on the version display screen to display information about the software on
the unit.
The folder number is updated and the file number starts from 0001.
A folder number between 100 and 999 can be assigned.
The folder number should be reset before it reaches 999. We recommend formatting the card
(P33) after saving the data on a PC or elsewhere.
To reset the folder number to 100, format the card first and then use this function to reset the
file number.
A reset screen for the folder number will then appear. Select [Yes] to reset the folder number.
When the setup/custom settings are reset, the following settings are also reset.
The [World Time] setting
The settings of [Travel Date] (departure date, return date, location)
The settings of [Rotate Disp.], [Picture Sort] and [Delete Confirmation] in the [Playback] menu
The folder number and the clock setting are not changed.
[Menu Information]
Explanations of the menu items and settings are displayed on the
menu screen.
[ON]/[OFF]
[Language]
Set the language displayed on the screen.
[Version Disp.]
[Exposure Comp.
Reset]
An exposure value can be reset when the Recording Mode is
changed or the camera is turned off.
[ON]/[OFF]
[No.Reset]
Reset the file number of the next recording to 0001.
[Reset]
The recording or setup/custom settings are reset to the default.
The following settings are reset to the default:
Recording settings (except for [Face Recog.] and [Profile Setup])
Recording settings ([Face Recog.] and [Profile Setup] settings)
Setup/custom settings

Table of Contents

Other manuals for Panasonic LUMIX DMC-G7

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-G7 and is the answer not in the manual?

Panasonic LUMIX DMC-G7 Specifications

General IconGeneral
Megapixel16.00 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size- \
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4592 x 3448 pixels
Image sensor size (W x H)17.3 x 13 mm
Still image resolution(s)4592 x 3448, 3232 x 2424, 2272 x 1704, 1824 x 1368, 4592 x 3064, 3232 x 2160, 2272 x 1520, 1824 x 1216, 4592 x 2584, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3424 x 3424, 2416 x 2416, 1712 x 1712, 1712 x 1712
Filter size52 mm
Optical zoom- x
Focal length range14 - 42 mm
Maximum aperture number22
Minimum aperture number3.5
Number of diaphragm blades7
Number of aspheric elements1
Lens structure (elements/groups)12/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)100
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/25 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/160 s
Flash range (wide)- m
Flash exposure correction±3EV (1/2; 1/3 EV step)
Video resolutions640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution3840 x 2160 pixels
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Vari-angle LCD display-
Display resolution (numeric)1040000 pixels
Viewfinder typeElectronic
USB version2.0
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesChildren, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effectsNegative film, Vivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
GPS (satellite)No
Self-timer delay2, 10 s
Power source typeBattery
Battery voltage7.2 V
Battery capacity1200 mAh
Battery life (CIPA standard)360 shots
Product colorBlack
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth77.4 mm
Width124.9 mm
Height86.2 mm
Weight360 g
Weight (including battery)410 g
