360
13. Others
Optional accessories
Some optional accessories may not be available in some countries.
After attaching the flash (DMW-FL360L, DMW-FL580L: optional), the
effective range will be increased when compared to the camera’s built
in flash.
Preparations:
Turn off the camera and close the built-in flash.
To change the settings for external flashes on the camera, refer to P233.
Refer to P238 about the settings for the wireless flash.
External Flash (optional)
Removing the Hot Shoe Cover
The camera comes with a hot shoe cover attached to the hot shoe.
Remove the hot shoe cover by pulling it in the
direction indicated by arrow
2
while pressing it in the
direction indicated by arrow
1
.
When the hot shoe is not in use, make sure to attach the hot
shoe cover.
Please be careful not to lose the hot shoe cover.
Keep the Hot Shoe Cover out of reach of children to prevent
swallowing.
When using other commercially available external flashes without
communication functions with the camera
It is necessary to set the exposure on the external flash. If you want to use the external flash
in Auto Mode, use an external flash that allows you to set the aperture value and the ISO
sensitivity to match the settings on the camera.
Set to Aperture-Priority AE Mode or Manual Exposure Mode on the camera and then set the
same aperture value and ISO sensitivity on the external flash. (The exposure cannot be
compensated adequately due to the change on the aperture value in Shutter-Priority AE
Mode and the external flash cannot control the light adequately in Program AE Mode
because the aperture value cannot be fixed.)

Table of Contents

Other manuals for Panasonic LUMIX DMC-G7

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-G7 and is the answer not in the manual?

Panasonic LUMIX DMC-G7 Specifications

General IconGeneral
Megapixel16.00 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size- \
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4592 x 3448 pixels
Image sensor size (W x H)17.3 x 13 mm
Still image resolution(s)4592 x 3448, 3232 x 2424, 2272 x 1704, 1824 x 1368, 4592 x 3064, 3232 x 2160, 2272 x 1520, 1824 x 1216, 4592 x 2584, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3424 x 3424, 2416 x 2416, 1712 x 1712, 1712 x 1712
Filter size52 mm
Optical zoom- x
Focal length range14 - 42 mm
Maximum aperture number22
Minimum aperture number3.5
Number of diaphragm blades7
Number of aspheric elements1
Lens structure (elements/groups)12/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)100
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/25 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/160 s
Flash range (wide)- m
Flash exposure correction±3EV (1/2; 1/3 EV step)
Video resolutions640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution3840 x 2160 pixels
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Vari-angle LCD display-
Display resolution (numeric)1040000 pixels
Viewfinder typeElectronic
USB version2.0
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesChildren, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effectsNegative film, Vivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
GPS (satellite)No
Self-timer delay2, 10 s
Power source typeBattery
Battery voltage7.2 V
Battery capacity1200 mAh
Battery life (CIPA standard)360 shots
Product colorBlack
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth77.4 mm
Width124.9 mm
Height86.2 mm
Weight360 g
Weight (including battery)410 g
