13. Others
362
Using a stereo shotgun microphone (DMW-MS2: optional) or stereo
microphone (VW-VMS10: optional), you can record sounds with
quality superior to those recorded with the built-in microphone.
Using the stereo shotgun microphone (DMW-MS2:optional), you
can switch between the gun (ultra-directional) recording and the
wide range stereo recording.
Preparations:
Close the built-in flash, and then turn this unit off.
Remove the hot shoe cover that is attached to the camera. (P360)
Setting the range within which the stereo shotgun microphone (DMW-MS2:
optional) will record sounds
1 Attach the dedicated stereo shotgun microphone to this unit, and then turn this
unit on.
2 Select [Special Mic.] on the [Motion Picture] menu. (P63)
The menu items are displayed only when the stereo shotgun microphone is connected.
3 Press 3/4 to select the Item and then press [MENU/SET].
4 (When [MANUAL] is selected)
Press 2/1 to select a range, and press [MENU/SET].
Reducing the wind noise when using an external microphone
The camera will effectively reduce the wind noise when recording sound with an external
microphone.
Settings: [HIGH]/[STANDARD]/[LOW]/[OFF]
This item is available only when using an external microphone.
Setting [Wind Cut] may alter the usual sound quality.
External Microphone (optional)
[STEREO]
Allows stereo recording of sound over a wide area.
[LENS AUTO]
Allows recording within the range that is set automatically according
to the angle of view of the lens.
[SHOTGUN]
Allows recording from one direction by shutting out background and
surrounding noise.
[S. SHOTGUN]
Allows recording within the range even narrower than that of
[SHOTGUN].
[MANUAL]
Allows recording within the range you set manually.
> [Motion Picture] > [Wind Cut]
MENU

Table of Contents

Other manuals for Panasonic LUMIX DMC-G7

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-G7 and is the answer not in the manual?

Panasonic LUMIX DMC-G7 Specifications

General IconGeneral
Megapixel16.00 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size- \
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4592 x 3448 pixels
Image sensor size (W x H)17.3 x 13 mm
Still image resolution(s)4592 x 3448, 3232 x 2424, 2272 x 1704, 1824 x 1368, 4592 x 3064, 3232 x 2160, 2272 x 1520, 1824 x 1216, 4592 x 2584, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3424 x 3424, 2416 x 2416, 1712 x 1712, 1712 x 1712
Filter size52 mm
Optical zoom- x
Focal length range14 - 42 mm
Maximum aperture number22
Minimum aperture number3.5
Number of diaphragm blades7
Number of aspheric elements1
Lens structure (elements/groups)12/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)100
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/25 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/160 s
Flash range (wide)- m
Flash exposure correction±3EV (1/2; 1/3 EV step)
Video resolutions640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution3840 x 2160 pixels
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Vari-angle LCD display-
Display resolution (numeric)1040000 pixels
Viewfinder typeElectronic
USB version2.0
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesChildren, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effectsNegative film, Vivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
GPS (satellite)No
Self-timer delay2, 10 s
Power source typeBattery
Battery voltage7.2 V
Battery capacity1200 mAh
Battery life (CIPA standard)360 shots
Product colorBlack
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth77.4 mm
Width124.9 mm
Height86.2 mm
Weight360 g
Weight (including battery)410 g
