Panasonic LUMIX DMC-G7 User Manual

381
13. Others
[Custom]
[Cust.Set Mem.] Registers the current camera settings as custom set. P128
[Silent Mode] Disables operational sounds and output of light at once. P212
[AF/AE Lock]
Sets the fixed content for focusing and exposure when the
AF/AE lock is on.
P172
[AF/AE Lock Hold]
This will set the operation of [AF/AE LOCK] button when
taking a picture with fixed focus or exposure.
P172
[Shutter AF]
Set whether or not the focus is adjusted automatically
when the shutter button is pressed halfway.
P162
[Half Press Release]
The shutter will immediately fire when the shutter button is
pressed halfway.
P162
[Quick AF]
Speeds up the focusing that takes place when you press
the shutter button.
P162
[Eye Sensor AF]
The camera automatically adjusts the focus when the eye
sensor is active.
P58
[Pinpoint AF Time]
Sets the time for which the screen is enlarged when the
shutter button is pressed halfway with Auto Focus Mode
set to [ ].
P159
[Pinpoint AF Display]
Sets whether to display the assist screen that appears
when Auto Focus Mode is set to [ ] in a window or full
screen.
P159
[AF Assist Lamp]
AF assist lamp will illuminate the subject when the shutter
button is pressed half-way making it easier for the camera
to focus when recording in low light conditions.
P163
[Direct Focus Area]
Moves the AF area or MF assist using the cursor button
when recording.
P157,
P167
[Focus/Release Priority] It will set so no picture can be taken when it is out of focus. P164
[AF+MF]
You can set the focus manually after the automatic focus
has finished.
P164
[MF Assist] Sets the display method of MF Assist (enlarged screen). P169
[MF Assist Display]
Sets whether MF Assist (enlarged screen) will appear in a
windowed screen display or in a full screen display.
P166
[MF Guide]
When you set the focus manually, an MF guide that allows
you to check the direction to achieve focus is displayed.
P169
[Peaking]
In-focus portions are highlighted when focus is being
adjusted manually.
P170

Panasonic LUMIX DMC-G7 Specifications

General

Megapixel	16.00 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	4592 x 3448, 3232 x 2424, 2272 x 1704, 1824 x 1368, 4592 x 3064, 3232 x 2160, 2272 x 1520, 1824 x 1216, 4592 x 2584, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3424 x 3424, 2416 x 2416, 1712 x 1712, 1712 x 1712
Filter size	52 mm
Optical zoom	- x
Focal length range	14 - 42 mm
Maximum aperture number	22
Minimum aperture number	3.5
Number of diaphragm blades	7
Number of aspheric elements	1
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/25 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Flash range (wide)	- m
Flash exposure correction	±3EV (1/2; 1/3 EV step)
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution	3840 x 2160 pixels
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Vari-angle LCD display	-
Display resolution (numeric)	1040000 pixels
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Children, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effects	Negative film, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
GPS (satellite)	No
Self-timer delay	2, 10 s
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	360 shots
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	77.4 mm
Width	124.9 mm
Height	86.2 mm
Weight	360 g
Weight (including battery)	410 g
