17
23 Focus mode dial
24 Flash open lever
25 Stereo microphone
26 Drive mode lever
Single:
Burst:
Auto Bracket:
Self-timer:
27 Shutter button
28 Focus distance reference mark
29 Hot shoe
30 Mode dial
31 Status indicator
32 [Q.MENU] button
33 [FILM MODE] button
34 [MIC/REMOTE] socket
35 Shoulder strap eyelet
s Be sure to attach the shoulder strap when
using the camera to ensure that you will not
drop it.
36 [HDMI] socket
37 [AV OUT/DIGITAL] socket
38 Card door
39 DC cable cover
40 Battery door
41 Release lever
42 Tripod receptacle
s When you use a tripod, make sure the tripod
is stable when the camera is attached to it.
Lens
H-VS014140 (LUMIX G VARIO HD 14–140 mm/F4.0–5.8 ASPH./MEGA O.I.S.)
43 Tele
44 Lens surface
45 Focus ring
46 Wide
47 Zoom ring
48 [O.I.S.] switch
49 Contact point
50 Lens fitting mark
Battery charger/AC adaptor
51 Power input socket [AC IN]
52 [CHARGE] indicator
53 Power output socket [DC OUT]
54 Battery holder
424140
45 46
49 50
48
47
43 44
