Panasonic Lumix DMC-GH1KPP User Manual

42
9.3. Disassembly Procedure
No. Item Fig Removal
1Rear Case Unit (Fig.D1)3 Screws (A)
1 Screw (B)
3 Screws (C)
4 Screws (D)
(Fig.D2) Eye Cap Unit
2 Screws (E)
FP9005(Flex)
FP9008(Flex)
P9003(Connector)
Rear Case Unit
2Top Case Unit (Fig.D3)2 Screws (F)
FP9002(Flex)
FP9007(Flex)
1 Screw (G)
1 Screw (H)
FP4002(Connector)
P8503(Connector)
P8504(Connector)
Top Ca s e U nit
3LVF Unit (Fig.D4)FP9006(Flex)
2 Screws (I)
LVF Unit
4Main P.C.B. (Fig.D5)1 Screw (J)
Jack Holder
FP9001(Flex)
FP9003(Flex)
FP9009(Flex)
FP9010(Flex)
FP9004(Flex)
P9001(Connector)
Main P.C.B.
5Audio P.C.B. (Fig.D6)1 Screw (K)
FP4001(Flex)
FP4003(Connector)
FP4004(Connector)
Audio P.C.B.
6Front Case Unit (Fig.D7)1 Screw (L)
Main P.C.B. Flex. Plate
FP8505(Flex)
(Fig.D8) Body Cap
4 Screws (M)
1 Screw (N)
1 Screw (O)
1 Screw (P)
Front Case Unit
7Battery Case Unit (Fig.D9)1 Screw (Q)
Battery Case Unit
8Speaker
DC Cover
(Fig.D10) 2 Screws (R)
Side Plate (L)
(Fig.D11) 1 Rib
Speaker
DC Cover
9Flash P.C.B. (Fig.D12)2 Screws (S)
P8507(Flex)
(Fig.D13) 2 Locking tabs
Audio P.C.B. Holder
P8502(Connector)
Solder (4 points)
Flash P.C.B.
10 Flash Sub P.C.B. Unit (Fig.D14) 1 Rib
P8502(Connector)
2 Ribs
(Fig.D15) Battery Lock Spring
Battery Lock Knob
Flash Sub P.C.B. Unit
11 AF Assist P.C.B.
EXT MIC P.C.B.
Remote P.C.B.
(Fig.D16) FP7701(Flex)
2 Screws (T)
Jack Cover
Remote Cover
AF Light Case
Side Frame (R)
AF Assist P.C.B.
(Fig.D17) 2 Screws (U)
Remote Holder
EXT MIC P.C.B.
Remote P.C.B.
12 Optical Sensor Unit (Fig.D18) Flex
1 Screw (V)
1 Screw (W)
Eye Piece Plate
Optical Sensor Unit
13 LCD Unit (Fig.D19) 2 Screws (X)
FPC Cover
1 Hanging part
(Fig.D20) 2 Ribs
Hinge Arm Cover Top
Hinge Arm Cover Bottom
2 Screws (Y)
LCD Unit
14 LCD TFT Unit (Fig.D21) 2 Screws (Z)
2 Screws (a)
LCD Case Bottom
LCD Hinge Unit
LCD IF P.C.B.
LCD BL Bezel Sheet
LCD Shield Case Unit
LCD Shield Case Top Unit
LCD TFT Unit
15 Mic P.C.B.
Mic Unit
(Fig.D22) 2 Screws (b)
2 Locking tabs
Flash Case Top Unit
1 Screw (c)
(Fig.D23) FP4201(Connector)
FP4202(Flex)
1 Screw (d)
3 Locking tabs
Mic Dumper
Mic Plate
Mic P.C.B.
Mic Unit
16 Battery Spring (Fig.D24) 3 Locking tabs
Battery Plate
Battery Catcher
Battery Spring
17 Battery Door Unit (Fig.D25) Battery Door Shaft
Battery Door Spring
Battery Door Unit
No. Item Fig Removal
