Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
------ P.C.B. LIST ------ ## VEP58084A REMOTE P.C.B. [PAVCSG](RTL)
## VEP56084A MAIN P.C.B. 1 PP,GC,GH,GK,GN,GT
(RTL) E.S.D. FP7350 K1KA20A00306 CONNECTOR 20P 1 [PAVCSG]
## VEP56084B MAIN P.C.B. 1 [PAVCSG]EB,EC,EG (RTL) E.S.D. FP7351 K1MN04BA0208 CONNECTOR 4P 1 [PAVCSG]
## VEP54012A AUDIO P.C.B. 1 (RTL) E.S.D.
## VEP58085A AF ASSIST P.C.B. 1 [PAVCSG](RTL) E.S.D. JK7350 K2HD104D0002 JACK 1 [PAVCSG]
## VEP54013A EXT MIC P.C.B. 1 [PAVCSG](RTL) E.S.D.
## VEP58084A REMOTE P.C.B. 1 [PAVCSG](RTL) LB7350 J0JCC0000415 FILTER 1 [PAVCSG]
## VEP58089A FLASH P.C.B. 1 [PAVCSG](RTL) E.S.D. LB7351 J0JCC0000415 FILTER 1 [PAVCSG]
## VEP58090A FLASH SUB P.C.B. 1 [PAVCSG](RTL) LB7352 J0JCC0000415 FILTER 1 [PAVCSG]
## VEP58086A HINGE SW P.C.B. 1 [PAVCSG](RTL) LB7353 J0JCC0000415 FILTER 1 [PAVCSG]
## VEP59057A LCD IF P.C.B. 1 [PAVCSG](RTL)
## VEP54014A MIC P.C.B. 1 (RTL) E.S.D. VA7350 D4ED18R00008 VARISTOR 1 [PAVCSG]
--- INDIVIDUAL PARTS ---
C7100 F2AZZ2310001 E. CAPACITOR 1 ## VEP58089A FLASH P.C.B. [PAVCSG](RTL) E.S.D.
P8501 K4ZZ04000050 BATTERY CATCHER 1
C8501 F1K2J333A029 C.CAPACITOR 630V 0.033U 1 [PAVCSG]
C8502 F1K2E2230002 C.CAPACITOR 250V 0.022U 1 [PAVCSG]
--- ELEC. COMPONENTS --- C8503 ECJ0EB1A104K C.CAPACITOR CH 10V 0.1U 1 [PAVCSG]
## VEP58085A AF ASSIST P.C.B. [PAVCSG](RTL) E.S.D. C8504 F1K2J102A028 C.CAPACITOR 630V 1000P 1 [PAVCSG]
C8506 ECJ1VB0J105K C.CAPACITOR CH 6.3V 1U 1 [PAVCSG]
D7701 B3ADB0000100 DIODE 1 [PAVCSG]E.S.D. C8507 F1J1A106A023 C.CAPACITOR CH 10V 10U 1 [PAVCSG]
FP7701 K1MN04BA0208 CONNECTOR 4P 1 [PAVCSG] D8501 B0ECGP000005 DIODE 1 [PAVCSG]E.S.D.
D8502 B0HCMP000006 DIODE 1 [PAVCSG]E.S.D.
D8503 MA2YF8000L DIODE 1 [PAVCSG]E.S.D.
## VEP54013A EXT MIC P.C.B. [PAVCSG](RTL) E.S.D. F8501 ERBSE3R00U FUSE 32V 3.0A 1 [PAVCSG]
F8502 ERBSE1R50U FUSE 32V 1.5A 1 [PAVCSG]
C4401 ECJ0EB1E472K C.CAPACITOR CH 25V 4700P 1 [PAVCSG]
C4402 ECJ0EB1E472K C.CAPACITOR CH 25V 4700P 1 [PAVCSG] FP8505 K1MN07BA0055 CONNECTOR 7P 1 [PAVCSG]
C4403 ECJ1VB0J475K C.CAPACITOR CH 6.3V 4.7U 1 [PAVCSG]
C4404 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 [PAVCSG] LB8501 J0JGC0000038 FILTER 1 [PAVCSG]
C4405 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 [PAVCSG]
C4406 F3E0J226A009 E.CAPACITOR CH 6.3V 22U 1 [PAVCSG] P8502 K1KA02B00307 CONNECTOR 2P 1 [PAVCSG]
C4407 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 [PAVCSG] P8503 K1KA02B00292 CONNECTOR 2P 1 [PAVCSG]
C4408 F3E0J226A009 E.CAPACITOR CH 6.3V 22U 1 [PAVCSG] P8504 K1KA02BA0022 CONNECTOR 2P 1 [PAVCSG]
C4409 F3F0J226A032 T.CAPACITOR CH 6.3V 22U 1 [PAVCSG] P8507 K1MN22BA0272 CONNECTOR 22P 1 [PAVCSG]
FP4400 K1KA20A00275 CONNECTOR 20P 1 [PAVCSG] Q8501 B1JBLP000017 TRANSISTOR 1 [PAVCSG]E.S.D.
FP4401 K1KA05BA0014 CONNECTOR 5P 1 [PAVCSG] Q8502 B1DFCG000020 TRANSISTOR 1 [PAVCSG]E.S.D.
Q4401 2SC6054J0L TRANSISTOR 1 [PAVCSG]E.S.D. QR8501 XP0431400L DIGITAL TRANSISTOR 1 [PAVCSG]E.S.D.
Q4402 2SC6054J0L TRANSISTOR 1 [PAVCSG]E.S.D. QR8502 UNR32AF00L TRANSISTOR RESISTOR 1 [PAVCSG]E.S.D.
Q4403 2SA2174J0L TRANSISTOR 1 [PAVCSG]E.S.D. QR8503 UNR32A100L TRANSISTOR-RESISTOR 1 [PAVCSG]E.S.D.
Q4404 2SC6054J0L TRANSISTOR 1 [PAVCSG]E.S.D. QR8504 UNR32A100L TRANSISTOR-RESISTOR 1 [PAVCSG]E.S.D.
Q4405 2SA2174J0L TRANSISTOR 1 [PAVCSG]E.S.D.
Q4406 2SC6054J0L TRANSISTOR 1 [PAVCSG]E.S.D. R8501 ERJ8GEYJ104V M.RESISTOR CH 1/8W 100K 1 [PAVCSG]
R8502 ERJ8GEYJ105V M.RESISTOR CH 1/8W 1M 1 [PAVCSG]
QR4401 UNR91A3J0L TRANSISTOR-RESISTOR 1 [PAVCSG]E.S.D. R8503 ERJ2GEJ104X M.RESISTOR CH 1/16W 100K 1 [PAVCSG]
R8504 ERJ3GEYJ220V M.RESISTOR CH 1/10W 22 1 [PAVCSG]
R4401 D0HB562ZA002 M.RESISTOR 5.6K 1 [PAVCSG] R8505 ERJ3GEYJ101V M.RESISTOR CH 1/10W 100 1 [PAVCSG]
R4402 D0HB331ZA002 M.RESISTOR CH 1/10W 330 1 [PAVCSG] R8506 ERJ6RED914V CHIP RESISTOR 1 [PAVCSG]
R4403 D0HB562ZA002 M.RESISTOR 5.6K 1 [PAVCSG] R8507 ERJ6RED914V CHIP RESISTOR 1 [PAVCSG]
R4404 ERJ2GEJ473X M.RESISTOR CH 1/16W 47K 1 [PAVCSG] R8508 ERJ2RKD304X M.RESISTOR CH 1/16W 300K 1 [PAVCSG]
R4405 ERJ2GEJ683X M.RESISTOR CH 1/16W 68K 1 [PAVCSG] R8509 ERJ2RHD163X M.RESISTOR CH 1/16W 16K 1 [PAVCSG]
R4406 ERJ2GEJ223X M.RESISTOR CH 1/16W 22K 1 [PAVCSG] R8510 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1 [PAVCSG]
R4407 ERJ2GEJ471X M.RESISTOR CH 1/16W 470 1 [PAVCSG] R8511 ERJ2GEJ153X M.RESISTOR CH 1/16W 15K 1 [PAVCSG]
R4408 D0HB103ZA002 M.RESISTOR CH 1/16W 10K 1 [PAVCSG] R8512 ERJ2GE0R00X M.RESISTOR CH 1/16W 0 1 [PAVCSG]
R4409 D0HB154ZA002 M.RESISTOR CH 1/16W 150K 1 [PAVCSG] R8513 ERJ2GEJ152X M.RESISTOR CH 1/16W 1.5K 1 [PAVCSG]
R4410 D0HB563ZA002 M.RESISTOR CH 1/10W 56K 1 [PAVCSG] R8514 ERJ8GEY0R00V M.RESISTOR CH 1/8W 0 1 [PAVCSG]
R4411 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1 [PAVCSG] R8515 ERJ2GEJ332X M.RESISTOR CH 1/16W 3.3K 1 [PAVCSG]
R4412 ERJ2GEJ562X M.RESISTOR CH 1/16W 5.6K 1 [PAVCSG] R8519 ERJ3GEY0R00V M.RESISTOR CH 1/10W 0 1 [PAVCSG]
R4413 ERJ2GEJ151X M.RESISTOR CH 1/16W 150 1 [PAVCSG] R8520 ERJ3GEY0R00V M.RESISTOR CH 1/10W 0 1 [PAVCSG]
R4414 ERJ2GEJ471X M.RESISTOR CH 1/16W 470 1 [PAVCSG]
R4415 D0HB103ZA002 M.RESISTOR CH 1/16W 10K 1 [PAVCSG] T8501 G5D1A0000074 TRANSFORMER 1 [PAVCSG]
R4416 D0HB154ZA002 M.RESISTOR CH 1/16W 150K 1 [PAVCSG]
R4417 D0HB563ZA002 M.RESISTOR CH 1/10W 56K 1 [PAVCSG]
R4418 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1 [PAVCSG]
R4419 ERJ2GEJ562X M.RESISTOR CH 1/16W 5.6K 1 [PAVCSG] ## VEP58086A HINGE SW P.C.B. [PAVCSG](RTL)
R4420 ERJ2GEJ151X M.RESISTOR CH 1/16W 150 1 [PAVCSG]
R4421 ERJ2GEJ472X M.RESISTOR CH 1/16W 4.7K 1 [PAVCSG] SW4901 K0L1BA000147 SWITCH 1 [PAVCSG]
