Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
63 VGQ0A30 LCD LOCK LEVER 1 [PAVCSG]
1 VEP56084A MAIN P.C.B. 1 PP,GC,GH,GK,GN,GT 64 VGQ0E39 GRIP PIECE REAR 1 [PAVCSG]
(RTL) E.S.D. 65 VGU0D13 REAR OP BUTTON 1 [PAVCSG]
1 VEP56084B MAIN P.C.B. 1 [PAVCSG]EB,EC,EG (RTL) E.S.D. 66 VGU0D14 PLAYBACK,AF/AE LOCK BUTION 1 [PAVCSG]
2 ML-421S/ZTE BUTTON BATTERY 1 (B4001)[ENERGY] 67 VGU0D47 LVF/LCD BUTTON 1 [PAVCSG]
3 VEP54012A AUDIO P.C.B. 1 (RTL) E.S.D. 68 VGU0E58 MOTION PICTURE BUTTON 1 [PAVCSG]
4 VMP9162 MAIN PCB FLEX. PLATE 1 [PAVCSG] 69 VMB4206 LCD LOCK SPRING 1 [PAVCSG]
5 VMP9266 FRONT GND PLATE 1 [PAVCSG] 70 VMB4207 SD DOOR SPRING 1 [PAVCSG]
6 VWJ2090 AUDIO FPC 1 [PAVCSG] 71 VMB4263 MOTION PICTURE BUTTON SPRING 1 [PAVCSG]
7 VXQ1770 MOUNT BOX UNIT 1 72 VMP9181 EYEPIECE PLATE 1 [PAVCSG]
8 VYF3227 EYE CAP UNIT 1 73 VMS7944 SD DOOR SHAFT 1 [PAVCSG]
9 K0RC01000003 FRONT OP UNIT 1 [PAVCSG] 74 VYF3263 SD DOOR UNIT 1 [PAVCSG](K)
10 VEP58085A AF ASSIST P.C.B. 1 [PAVCSG](RTL) E.S.D. 74 VYF3255 SD DOOR UNIT 1 [PAVCSG](N)
11 VGK3530 GRIP PIECE FRONT 1 [PAVCSG] 74 VYF3267 SD DOOR UNIT 1 [PAVCSG](R)
12 VGQ0A13 AF LIGHT CASE 1 [PAVCSG] 75 VEE1F12 HINGE SW HARNESS 1 [PAVCSG]
13 VKF4379 REMOTE COVER 1 [PAVCSG](K) 76 VEP58086A HINGE SW P.C.B. 1 [PAVCSG](RTL)
13 VKF4542 REMOTE COVER 1 [PAVCSG](N) 77 VMA0W24 HINGE EARTH PLATE 1 [PAVCSG]
13 VKF4412 REMOTE COVER 1 [PAVCSG](R) 78 VYQ4488-A STRAP R UNIT 1 [PAVCSG]
14 VKF4530 JACK COVER 1 [PAVCSG](K) 79 VYQ4925 STRAP L UNIT 1 [PAVCSG]
14 VKF4543 JACK COVER 1 [PAVCSG](N) 80 VEP59057A LCD IF P.C.B. 1 [PAVCSG](RTL)
14 VKF4548 JACK COVER 1 [PAVCSG](R) 81 VGQ0B55 LCD BL BEZEL SHEET 1 [PAVCSG]
15 VMB4198 LENS RELEASE BUTTON SPRING 1 [PAVCSG] 82 VKM8069 LCD CASE BOTTOM 1 [PAVCSG](K)
16 VMP9191 FRONT EARTH PLATE 1 [PAVCSG] 82 VKM7996 LCD CASE BOTTOM 1 [PAVCSG](N)
17 VYQ4928 SHUTTER RING UNIT 1 [PAVCSG] 82 VKM8070 LCD CASE BOTTOM 1 [PAVCSG](R)
18 VYQ4929 LENS RELEASE BUTTON UNIT 1 [PAVCSG] 83 VMT1964 LCD PCB CUSION 1 [PAVCSG]
19 VEP54013A EXT MIC P.C.B. 1 [PAVCSG](RTL) E.S.D. 84 VYF3261 LCD HINGE UNIT 1 [PAVCSG](K)
20 VEP58084A REMOTE P.C.B. 1 [PAVCSG](RTL) 84 VYF3256 LCD HINGE UNIT 1 [PAVCSG](N)
21 VGQ0E37 REMOTE HOLDER 1 [PAVCSG] 84 VYF3262 LCD HINGE UNIT 1 [PAVCSG](R)
22 VGQ0F03 REMOTE PCB SHEET 1 [PAVCSG] 85 VYQ4552 LVF UNIT 1
23 VMP9348 SIDE FRAME R 1 [PAVCSG] 85-1 VGP6235 LVF PANEL 1
24 VWJ2087 FRONT FPC 1 [PAVCSG] 85-2 VGQ0A40 LVF COVER 1
25 F2AZZ2310001 E. CAPACITOR 1 [PAVCSG](C7100) 86 VYK3H88 FRONT CASE UNIT 1 [PAVCSG](K)
26 K4ZZ04000050 BATTERY CATCHER 1 [PAVCSG](P8501) 86 VYK3H90 FRONT CASE UNIT 1 [PAVCSG](N)
27 L0AA01A00039 SPEAKER 1 [PAVCSG] 86 VYK3H89 FRONT CASE UNIT 1 [PAVCSG](R)
28 VEE1F10 FLASH HARNESS 1 [PAVCSG] 87 VYK3H91 REAR CASE UNIT 1 [PAVCSG](K)
29 VEP58089A FLASH P.C.B. 1 [PAVCSG](RTL) E.S.D. 87 VYK3H93 REAR CASE UNIT 1 [PAVCSG](N)
30 VEP58090A FLASH SUB P.C.B. 1 [PAVCSG](RTL) 87 VYK3H92 REAR CASE UNIT 1 [PAVCSG](R)
31 VGQ0D53 CAPACITOR CUSHION 1 [PAVCSG] 88 VYK2Y66 LCD TFT UNIT 1 [PAVCSG]
32 VGQ0E38 AUDIO PCB HOLDER 1 [PAVCSG] 89 VYK2Y62 LCD CASE TOP UNIT 1 [PAVCSG](K)
33 VGQ0E42 CAPACITOR HOLDER 1 [PAVCSG] 89 VYK3G39 LCD CASE TOP UNIT 1 [PAVCSG](N)
34 VGQ0F84 SPEAKER CUSHION 1 [PAVCSG] 89 VYK3J36 LCD CASE TOP UNIT 1 [PAVCSG](R)
35 VGU0D11 BATTERY LOCK KNOB 1 [PAVCSG] 90 VYK2Y65 LCD SHILD CASE UNIT 1 [PAVCSG]
36 VKF4380 DC COVER 1 [PAVCSG](K) 91 VEE1G17 EXT MIC HARNESS 1 [PAVCSG]
36 VKF4544 DC COVER 1 [PAVCSG](N) 92 VGQ0E40 JACK HOLDER 1 [PAVCSG]
36 VKF4411 DC COVER 1 [PAVCSG](R) 93 VMT1964 LCD PCB CUSHION 1 [PAVCSG]
37 VKM7947 BATTERY CASE 1 [PAVCSG] 94 VMT1964 LCD PCB CUSHION 1 [PAVCSG]
38 VMB4199 BATTERY LOCK SPRING 1 [PAVCSG] 95 VMT1964 LCD PCB CUSHION 1 [PAVCSG]
39 VMB4201 BATTERY SPRING 1 [PAVCSG] 96 L5EDDXL00001 LVF MODULE 1
40 VMB4202 EARTH SPRING 1 [PAVCSG] 97 VWJ2061 LVF FPC 1
41 VMB4214 BATTERY DOOR SPRING 1 [PAVCSG] 98 VGQ0H23 BATTERY SIDE L CUSHION 1 [PAVCSG]
42 VMP9349 BATTERY PLATE 1 [PAVCSG] 99 VGQ0H25 BATT GND SHEET 1 [PAVCSG]
43 VMP9350 SIDE PLATE L 1 [PAVCSG] 100 VGQ0F03 REMOTE PCB SHEET 1 [PAVCSG]
44 VMS7941 BATTERY DOOR SHAFT 1 [PAVCSG] 101 VGQ0H24 FRONT OP SHEET 1 [PAVCSG]
45 VXK1907 TRIPOD FRAME UNIT 1 [PAVCSG] 102 VGQ0H61 TOP MIC SHEET 1 [PAVCSG]
46 VYF3224 BATTERY DOOR UNIT 1 [PAVCSG](K) 103 VGQ0H61 TOP MIC SHEET 1 [PAVCSG]
46 VYF3254 BATTERY DOOR UNIT 1 [PAVCSG](N) 104 VGQ0H80 HINGE ARM COVER SHEET 1 [PAVCSG]
46 VYF3268 BATTERY DOOR UNIT 1 [PAVCSG](R)
47 K0RE01100001 TOP CASE UNIT 1 [PAVCSG] B1 XQN16+BJ4FN SCREW 1 [PAVCSG]
48 VEK0P00 FLASH UNIT 1 [PAVCSG] B2 XQN16+BJ4FN SCREW 1 [PAVCSG]
49 VGQ0E41 MIC NET 1 [PAVCSG] B3 XQN16+BJ4FN SCREW 1 [PAVCSG]
50 VGQ0F87 MIC NET SHEET 1 [PAVCSG] B4 XQN16+BJ4FN SCREW 1 [PAVCSG]
51 VGQ0G78 FLASH TOP SHEET 1 [PAVCSG] B5 XQN16+BJ4FN SCREW 1 [PAVCSG]
52 VKM7949 FLASH CASE TOP 1 [PAVCSG] B6 XQN16+B2FN SCREW 1 [PAVCSG]
53 K1PY04Y00101 LEAD WIRE 1 [PAVCSG] B7 XQN16+B2FN SCREW 1 [PAVCSG]
54 VEP54014A MIC P.C.B. 1 (RTL) E.S.D. B8 VHD2062-A SCREW 1 [PAVCSG]
55 VMP9352 MIC PLATE 1 [PAVCSG] B9 XQN16+BJ4FN SCREW 1 [PAVCSG]
56 VMT1962 MIC DAMPER 1 [PAVCSG] B10 XQN16+BJ4FN SCREW 1 [PAVCSG]
57 WM-58A601 MICROPHONE UNIT 1 [PAVCSG] B11 XQN16+BJ4FN SCREW 1 [PAVCSG]
58 VKF4584 FPC COVER 1 B12 XQN16+BJ4FN SCREW 1 [PAVCSG]
59 VKM8063 HINGE ARM COVER TOP 1 [PAVCSG](K) B13 XQN16+BJ4FN SCREW 1 [PAVCSG]
59 VKM7993 HINGE ARM COVER TOP 1 [PAVCSG](N) B14 XQN16+BJ4FN SCREW 1 [PAVCSG]
59 VKM8064 HINGE ARM COVER TOP 1 [PAVCSG](R) B15 VHD2062-A SCREW 1 [PAVCSG]
60 VKM8065 HINGE ARM COVER BOTTOM 1 [PAVCSG](K) B16 VHD2062-A SCREW 1 [PAVCSG]
60 VKM7994 HINGE ARM COVER BOTTOM 1 [PAVCSG](N) B17 VHD2062-A SCREW 1 [PAVCSG]
60 VKM8066 HINGE ARM COVER BOTTOM 1 [PAVCSG](R) B18 VHD2062-A SCREW 1 [PAVCSG]
61 K0RC01000002 REAR OP UNIT 1 [PAVCSG] B19 VHD2062-A SCREW 1 [PAVCSG]
62 L2CH00000028 OPTICAL SENSOR UNIT 1 [PAVCSG] B20 VHD2062-A SCREW 1 [PAVCSG]
