1. Before Use
Names and Functions of Components
∫ Camera body
1 Self-timer indicator (P174)/
AF Assist Lamp (P145)
2 Sensor
3 Flash (P200)
4 Lens fitting mark (P21)
5 Mount
6 Lens lock pin
7 Lens release button (P20)
8 Flash open lever (P200)
•
The flash opens, and recording with the flash
becomes possible.
9 Speaker (P47)
•
Be careful not to cover the speaker with your
finger. Doing so may make sound difficult to hear.
10 Motion picture button (P208)
11 [(] (Playback) button (P65)
12 Touch screen (P15)/monitor (P306)
13 [MENU/SET] button (P17, 37)
14 [ ] (Delete) button (P71)/
[ ] (Quick Menu/Return) button (P40)
15 Control dial (P17)
16 [DISP.] button (P62, 69)
•
Each time this is pressed, the display on the monitor is switched.
17 Cursor buttons (P17)
3/[È] (Exposure Compensation) (P79, 88, 106, 157)
1/[ ] (White Balance) (P123)
2/[ ] (Auto Focus Mode) (P135)
4/[ ] (Drive mode) (P167)
Single (P57)/Burst (P168)/Auto bracket (P171)/Self-timer (P174)
2
3
1
45 67
