262
12. Using the Wi-Fi function
Methods for sending and images that can be sent
Some images may not be played back or sent depending on the device.
For information on the playback of images, check the web service.
For details on how to send images, refer to P280.
Click the followings to jump to the beginning of each menu.
Images uploaded to the web service cannot be displayed or deleted with this camera. Check
images by accessing the web service with your smartphone/tablet or computer.
If sending images fails, a report email outlining the failure will be sent to the email address
registered with “LUMIX CLUB”.
Images may contain personal information that can be used to identify the user, such as a
title, the time and date when the images was taken, and the location where the image
was taken. Check this information before uploading images to web services.
When sending images to web service
JPEG RAW MP4 AVCHD 3D
Sending an image each time a
recording is made
([Send Images While Recording])
± ———±
Select and send the images
([Send Images Stored in the Camera])
± ± ±
Sending an image each time a recording is made ([Send Images While
Recording]) P263
Select and send the images ([Send Images Stored in the Camera]) P264
Panasonic assumes no responsibility for the damages resulting from the leakage, loss, etc.
of images uploaded on web services.
When uploading images to the web service, do not delete images from this camera, even
after they have finished sending, until you have checked that they have been properly
uploaded to the web service. Panasonic assumes no responsibility for the damages
resulting from the deletion of images stored in this unit.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-GM1 and is the answer not in the manual?

Panasonic LUMIX DMC-GM1 Specifications

General IconGeneral
Filter size37 mm
Digital zoom4 x
Optical zoom- x
Extra/Smart zoom2.4 x
Focal length range12 - 32 mm
Lens mount interfaceMicro Four Thirds (MFT)
Maximum aperture number5.6
Minimum aperture number3.5
Number of diaphragm blades7
Number of aspheric elements3
Lens structure (elements/groups)8/7
Maximum focal length (35mm film equiv)64 mm
Minimum focal length (35mm film equiv)24 mm
Megapixel16 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size- \
Image formats supportedJPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Image sensor size (W x H)17.3 x 13 mm
Image stabilizer locationLens
Still image resolution(s)4592 x 3448 3232 x 2424 2272 x 1704 1824 x 1368 4592 x 3064 3232 x 2160 2272 x 1520 1824 x 1216 4592 x 2584 3232 x 1824 1920 x 1080 1824 x 1024 3424 x 3424 2416 x 2416 1712 x 1712
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Near Field Communication (NFC)No
FocusTTL
Focus adjustmentAuto/Manual
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance0.2 m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)125
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeElectronic
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed0.02 s
Flash range (wide)- m
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed640x480@30fps, 1280x720@30fps, 1920x1080@30fps
Audio systemstereo
Audio formats supportedAAC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Vari-angle LCD display-
Display resolution (numeric)1036000 pixels
USB version2.0
HDMI connector typeMicro
Scene modesChildren, Night landscape, Party (indoor), Portrait, Sunset
Photo effectsBlack&White, Skin tones, Vivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3, RAW
On Screen Display (OSD) languagesENG, ESP
Power source typeBattery
Battery typeH-H020A
Battery voltage7.2 V
Battery capacity680 mAh
Battery life (CIPA standard)220 shots
Number of batteries supported1
Product colorBlue
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Bundled softwarePHOTOfunSTUDIO 9.2 AE
Weight and Dimensions IconWeight and Dimensions
Depth30.4 mm
Width98.5 mm
Height54.9 mm
Weight173 g
Lens weight70 g
Lens diameter55.5 mm
Weight (including battery)204 g
