184
8. Functions Customised for Various Subjects and Purposes
Disabling Operational Sounds and the Output of
Light at once
([Silent Mode])
Applicable modes:
This function is useful for recording images in a quiet environment, public facility, etc. or
recording images of subjects such as babies or animals.
Select the menu. (P37)
Settings: [ON]/[OFF]
Operational sounds are muted, and the flash and the AF Assist lamp are forced off.
The following settings are fixed.
[Shutter Type]: [ESHTR]
[Flash Mode]: [Œ] (forced flash off)
[AF Assist Lamp]: [OFF]
[Beep Volume]: [s] (OFF)
[Shutter Vol.]: [ ] (OFF)
[Speaker Volume]: 0
Even when [ON] is set, the following functions light up/flash.
Status indicator
Self-timer indicator
Wi-Fi connection lamp
Operational sounds of the camera, such as those made by the lens aperture or focus
operations, are not turned off.
Be sure to pay special attention to the privacy, the likeness rights, etc. of the subject
when you use this function. Use at your own risk.
[MENU] > [Custom] > [Silent Mode]

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-GM1 and is the answer not in the manual?

Panasonic LUMIX DMC-GM1 Specifications

General IconGeneral
Filter size37 mm
Digital zoom4 x
Optical zoom- x
Extra/Smart zoom2.4 x
Focal length range12 - 32 mm
Lens mount interfaceMicro Four Thirds (MFT)
Maximum aperture number5.6
Minimum aperture number3.5
Number of diaphragm blades7
Number of aspheric elements3
Lens structure (elements/groups)8/7
Maximum focal length (35mm film equiv)64 mm
Minimum focal length (35mm film equiv)24 mm
Megapixel16 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size- \
Image formats supportedJPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Image sensor size (W x H)17.3 x 13 mm
Image stabilizer locationLens
Still image resolution(s)4592 x 3448 3232 x 2424 2272 x 1704 1824 x 1368 4592 x 3064 3232 x 2160 2272 x 1520 1824 x 1216 4592 x 2584 3232 x 1824 1920 x 1080 1824 x 1024 3424 x 3424 2416 x 2416 1712 x 1712
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Near Field Communication (NFC)No
FocusTTL
Focus adjustmentAuto/Manual
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance0.2 m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)125
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeElectronic
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed0.02 s
Flash range (wide)- m
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed640x480@30fps, 1280x720@30fps, 1920x1080@30fps
Audio systemstereo
Audio formats supportedAAC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Vari-angle LCD display-
Display resolution (numeric)1036000 pixels
USB version2.0
HDMI connector typeMicro
Scene modesChildren, Night landscape, Party (indoor), Portrait, Sunset
Photo effectsBlack&White, Skin tones, Vivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3, RAW
On Screen Display (OSD) languagesENG, ESP
Power source typeBattery
Battery typeH-H020A
Battery voltage7.2 V
Battery capacity680 mAh
Battery life (CIPA standard)220 shots
Number of batteries supported1
Product colorBlue
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Bundled softwarePHOTOfunSTUDIO 9.2 AE
Weight and Dimensions IconWeight and Dimensions
Depth30.4 mm
Width98.5 mm
Height54.9 mm
Weight173 g
Lens weight70 g
Lens diameter55.5 mm
Weight (including battery)204 g
