Panasonic LUMIX DMC-GM1 User Manual

25
2. Preparations before Recording
∫ About the [CHARGE] indicator
•
When the [CHARGE] indicator flashes
– The battery temperature is too high or too low. It is recommended to charge the battery again
in an ambient temperature of between 10 oC and 30 oC (50 oF and 86 oF).
– The terminals of the charger or the battery are dirty. In this case, wipe them with a dry cloth.
∫ Charging time
•
The indicated charging time is for when the battery has been discharged completely.
The charging time may vary depending on how the battery has been used.
The charging time for the battery in hot/cold environments or a battery that has not been
used for a long time may be longer than normal.
∫ Battery indication
•
The indication turns red and blinks if the remaining battery power is exhausted.
(The status indicator also blinks)
Recharge the battery or replace it with a fully charged battery.
• Do not leave any metal items (such as clips) near the contact areas of the power plug.
Otherwise, a fire and/or electric shocks may be caused by short-circuiting or the
resulting heat generated.
• The battery can be recharged even when it still has some charge left, but it is not
recommended that the battery charge be frequently topped up while the battery is fully
charged.
(Since characteristic swelling may occur.)
On: Charging.
Off: Charging has completed.
(Disconnect the charger from the electrical socket and detach the
battery after charging is completed.)
Charging time Approx. 130 min
98
AFSAFS
L
4:3

Panasonic LUMIX DMC-GM1 Specifications

General

Filter size	37 mm
Digital zoom	4 x
Optical zoom	- x
Extra/Smart zoom	2.4 x
Focal length range	12 - 32 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	5.6
Minimum aperture number	3.5
Number of diaphragm blades	7
Number of aspheric elements	3
Lens structure (elements/groups)	8/7
Maximum focal length (35mm film equiv)	64 mm
Minimum focal length (35mm film equiv)	24 mm
Megapixel	16 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Lens
Still image resolution(s)	4592 x 3448 3232 x 2424 2272 x 1704 1824 x 1368 4592 x 3064 3232 x 2160 2272 x 1520 1824 x 1216 4592 x 2584 3232 x 1824 1920 x 1080 1824 x 1024 3424 x 3424 2416 x 2416 1712 x 1712
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Near Field Communication (NFC)	No
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance	0.2 m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	125
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	0.02 s
Flash range (wide)	- m
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@30fps
Audio system	stereo
Audio formats supported	AAC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Vari-angle LCD display	-
Display resolution (numeric)	1036000 pixels
USB version	2.0
HDMI connector type	Micro
Scene modes	Children, Night landscape, Party (indoor), Portrait, Sunset
Photo effects	Black&White, Skin tones, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
On Screen Display (OSD) languages	ENG, ESP
Power source type	Battery
Battery type	H-H020A
Battery voltage	7.2 V
Battery capacity	680 mAh
Battery life (CIPA standard)	220 shots
Number of batteries supported	1
Product color	Blue
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Bundled software	PHOTOfunSTUDIO 9.2 AE

Weight and Dimensions

Depth	30.4 mm
Width	98.5 mm
Height	54.9 mm
Weight	173 g
Lens weight	70 g
Lens diameter	55.5 mm
Weight (including battery)	204 g
