13. Connecting to other equipment
∫ Transferring images to a PC
Preparations:
Install “PHOTOfunSTUDIO” to the PC.
1
Connect the computer and camera with the USB connection cable
(supplied).
• Please turn this unit on and your PC before connecting.
• Check the direction of the terminals and plug in/out straight holding onto the plug.
(It may result in malfunction by the deforming of the terminal if it is plugged in obliquely
or in wrong direction.)
Do not connect devices to incorrect terminals. Doing so may cause malfunction.
• Do not use any other USB connection cables except the supplied one or a genuine
Panasonic USB connection cable (DMW-USBC1: optional).
A USB connection cable (supplied)
B Align the marks, and insert.
C Place the camera in an upright position, and find the gold terminal at the bottom.
2
Press 3/4 to select [PC], and then press [MENU/SET].
• If [USB Mode] (P49) is set to [PC] in the [Setup] menu in advance, the camera will be
automatically connected to the PC without displaying the [USB Mode] selection screen.
• When the camera is connected to a PC while [USB Mode] is set to [PictBridge(PTP)], a
message may appear on the PC screen. In that case, close the message, and remove
the USB connection cable safely, and then set the
[USB Mode] to [PC].
3
Copy the images to a PC using “PHOTOfunSTUDIO”.
• Do not delete or move copied files or folders in Windows Explorer.
When viewing in “PHOTOfunSTUDIO”, you will not be able to play back or edit.

Panasonic LUMIX DMC-GM1 Specifications

General

Filter size	37 mm
Digital zoom	4 x
Optical zoom	- x
Extra/Smart zoom	2.4 x
Focal length range	12 - 32 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	5.6
Minimum aperture number	3.5
Number of diaphragm blades	7
Number of aspheric elements	3
Lens structure (elements/groups)	8/7
Maximum focal length (35mm film equiv)	64 mm
Minimum focal length (35mm film equiv)	24 mm
Megapixel	16 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Lens
Still image resolution(s)	4592 x 3448 3232 x 2424 2272 x 1704 1824 x 1368 4592 x 3064 3232 x 2160 2272 x 1520 1824 x 1216 4592 x 2584 3232 x 1824 1920 x 1080 1824 x 1024 3424 x 3424 2416 x 2416 1712 x 1712
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Near Field Communication (NFC)	No
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance	0.2 m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	125
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	0.02 s
Flash range (wide)	- m
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@30fps
Audio system	stereo
Audio formats supported	AAC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Vari-angle LCD display	-
Display resolution (numeric)	1036000 pixels
USB version	2.0
HDMI connector type	Micro
Scene modes	Children, Night landscape, Party (indoor), Portrait, Sunset
Photo effects	Black&White, Skin tones, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
On Screen Display (OSD) languages	ENG, ESP
Power source type	Battery
Battery type	H-H020A
Battery voltage	7.2 V
Battery capacity	680 mAh
Battery life (CIPA standard)	220 shots
Number of batteries supported	1
Product color	Blue
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Bundled software	PHOTOfunSTUDIO 9.2 AE

Weight and Dimensions

Depth	30.4 mm
Width	98.5 mm
Height	54.9 mm
Weight	173 g
Lens weight	70 g
Lens diameter	55.5 mm
Weight (including battery)	204 g
