Panasonic LUMIX DMC-GM1 User Manual

343
14. Others
• Do not press the monitor with excessive force. Uneven colours may appear on the monitor and
it may malfunction.
• If the camera is cold when you turn it on, the picture on the Monitor will be slightly darker than
usual at first. However, the picture will return to normal brightness when the internal
temperature of the camera increases.
• Do not press the lens with excessive force.
• Do not leave the camera with the lens facing the sun as rays of light from the sun may cause it
to malfunction. Also, be careful when placing the camera outside or near a window.
• When there is dirt (water, oil, and fingerprints, etc.) on the surface of the lens, the picture may
be affected. Lightly wipe the surface of the lens with a soft, dry cloth before and after taking
pictures.
• Do not place the lens mount facing downwards. Do not allow the lens
mount contacts A to become dirty.
About the Monitor
Extremely high precision technology is employed to produce the Monitor
screen. However there may be some dark or bright spots (red, blue or green) on
the screen. This is not a malfunction. Though the Monitor screen parts are
produced with highly controlled precision technology, some pixels may be
inactive or always lit. The spots will not be recorded on pictures on a card.
About the Lens

Panasonic LUMIX DMC-GM1 Specifications

General

Filter size	37 mm
Digital zoom	4 x
Optical zoom	- x
Extra/Smart zoom	2.4 x
Focal length range	12 - 32 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	5.6
Minimum aperture number	3.5
Number of diaphragm blades	7
Number of aspheric elements	3
Lens structure (elements/groups)	8/7
Maximum focal length (35mm film equiv)	64 mm
Minimum focal length (35mm film equiv)	24 mm
Megapixel	16 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Lens
Still image resolution(s)	4592 x 3448 3232 x 2424 2272 x 1704 1824 x 1368 4592 x 3064 3232 x 2160 2272 x 1520 1824 x 1216 4592 x 2584 3232 x 1824 1920 x 1080 1824 x 1024 3424 x 3424 2416 x 2416 1712 x 1712
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Near Field Communication (NFC)	No
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance	0.2 m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	125, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	125
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	0.02 s
Flash range (wide)	- m
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@30fps
Audio system	stereo
Audio formats supported	AAC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Vari-angle LCD display	-
Display resolution (numeric)	1036000 pixels
USB version	2.0
HDMI connector type	Micro
Scene modes	Children, Night landscape, Party (indoor), Portrait, Sunset
Photo effects	Black&White, Skin tones, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
On Screen Display (OSD) languages	ENG, ESP
Power source type	Battery
Battery type	H-H020A
Battery voltage	7.2 V
Battery capacity	680 mAh
Battery life (CIPA standard)	220 shots
Number of batteries supported	1
Product color	Blue
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Bundled software	PHOTOfunSTUDIO 9.2 AE

Weight and Dimensions

Depth	30.4 mm
Width	98.5 mm
Height	54.9 mm
Weight	173 g
Lens weight	70 g
Lens diameter	55.5 mm
Weight (including battery)	204 g
