Panasonic Lumix DMC-TZ100 User Manual

21
SQW0550
Before Use
TZ80/TZ81
Names and Functions of Main Parts
1 2
54
7 8
9
10
1314
15
16
6
11
12
3
1
Shutter button (→46)
2
Zoom lever (→45)
3
Motion picture button (→48)
4
Mode dial (→49)
Use this to select the recording mode.
5
Camera [ON/OFF] button (→42)
6
Stereo microphone (→44)
Be careful not to cover the microphone
with your finger. Doing so may make
sound difficult to record.
7
Viewfinder (→58)
8
Diopter adjustment dial (→60)
9
Eye sensor (→58, 60)
10
Strap eyelet (→23)
11
Speaker (→44)
Be careful not to cover the speaker with
your finger. Doing so may make sound
difficult to hear.
12
Control ring (→51)
Allows you to zoom and adjust settings
when recording.
13
Lens barrel
14
Lens
15
Flash (→241)
16
Self-timer indicator (→208) /
AF Assist Lamp (→164)

Panasonic Lumix DMC-TZ100 Specifications

General

Effective Pixels	20.1 Megapixels
Lens	LEICA DC VARIO-ELMARIT
Aperture	F2.8 - F5.9
Battery Life	Approx. 300 shots (CIPA Standard)
Dimensions	110.5 x 64.5 x 44.3 mm
Image Processor	Venus Engine
Built-in Flash	Yes
Sensor	1-inch High Sensitivity MOS Sensor
ISO Sensitivity	125-12800 (expandable to 80-25600)
Shutter Speed	60 - 1/2000 sec (Mechanical)
Video Recording	4K UHD (3840 x 2160) at 30p
Viewfinder	0.2-inch 1, 166k-dot EVF
LCD Monitor	3.0-inch TFT LCD (1, 040k dots)
Image Stabilization	5-axis Hybrid O.I.S. (Optical Image Stabilizer)
Weight	Approx. 312g
Connectivity	Wi-Fi, USB 2.0
Storage Media	SD, SDHC, SDXC Memory Card
Focal Length	25-250mm (35mm equivalent)
