Panasonic Lumix DMC-TZ100 User Manual

44
SQW0550
Basics
Holding the camera
Hold the camera gently with both hands keeping your arms close to your body
while standing with your feet slightly apart.
• To prevent dropping, be sure to attach the supplied strap and fit it to your wrist.
• Do not block the flash, AF Assist Lamp, microphone, or speaker with your fingers
or other objects.
• Make sure that the camera does not move at the moment the shutter button is pressed.
• Make sure your footing is stable and there is no danger of colliding with another person
or object in the vicinity while taking pictures.
TZ100/TZ101
TZ80/TZ81
AF Assist Lamp
Microphone
Speaker
Hand strap
Flash
Flash/AF Assist Lamp
Microphone
Speaker
Hand strap
■
About the direction detect function
Still pictures recorded with the camera held vertically can
be automatically displayed in portrait orientation during
playback. (Only when [Rotate Disp.] is set to [ON].)
• The direction detect function may not operate correctly if
pictures are taken with the camera pointing up or down.
• Motion pictures, 4K burst files recorded with the 4K Photo
function, and pictures recorded in [Post Focus] cannot be
displayed vertically.

Panasonic Lumix DMC-TZ100 Specifications

General

Effective Pixels	20.1 Megapixels
Lens	LEICA DC VARIO-ELMARIT
Aperture	F2.8 - F5.9
Battery Life	Approx. 300 shots (CIPA Standard)
Dimensions	110.5 x 64.5 x 44.3 mm
Image Processor	Venus Engine
Built-in Flash	Yes
Sensor	1-inch High Sensitivity MOS Sensor
ISO Sensitivity	125-12800 (expandable to 80-25600)
Shutter Speed	60 - 1/2000 sec (Mechanical)
Video Recording	4K UHD (3840 x 2160) at 30p
Viewfinder	0.2-inch 1, 166k-dot EVF
LCD Monitor	3.0-inch TFT LCD (1, 040k dots)
Image Stabilization	5-axis Hybrid O.I.S. (Optical Image Stabilizer)
Weight	Approx. 312g
Connectivity	Wi-Fi, USB 2.0
Storage Media	SD, SDHC, SDXC Memory Card
Focal Length	25-250mm (35mm equivalent)
