Panasonic LUMIX DMC-ZS100 User Manual

159
SQW0547
Adjusting the focus and brightness (exposure)
Taking pictures with Auto Focus
■
ZS100
When selecting [ ]
You can enlarge the screen to perform more precise settings of the focus position.
• You cannot set the focus position at the edges of the screen.
Set the menu
→ [Rec] → [AF Mode]
Select [ ] and press
Use to set the focus position and press
[MENU/SET]
• The enlarged assist screen will appear for setting the focus
position.
• The assist screen can also be displayed by touching the
subject.
Move [+] to the focus position with
Operation Touch operation Description
Touch Moves [+].
— Pinch in / Pinch out Enlarges/reduces the AF area in small steps.
— Enlarges/reduces the AF area in large steps.
—
Switches the enlarged display. (windowed/full
screen)
[DISP.] [Reset] Resets [+] back to the center.
• The image of a part of the screen can be enlarged or reduced approximately 3 to 6 times. The
image of the entire screen can be enlarged or reduced approximately 3 to 10 times.
• If you use the HDMI output during recording, the screen cannot be enlarged in windowed
mode.
• On the assist screen, it is also possible to record a picture by touching [
].

Panasonic LUMIX DMC-ZS100 Specifications

General

Effective Pixels	20.1 Megapixels
Optical Zoom	10x
Lens	LEICA DC VARIO-ELMARIT
Screen Size	3.0-inch
LCD Screen Resolution	1, 040, 000 dots
Viewfinder Resolution	1, 166, 000 dots
NFC	No
GPS	No
Built-in Flash	Yes
Sensor Type	MOS
Focal Length	25-250mm (35mm equivalent)
Maximum Aperture	F2.8-5.9
ISO Sensitivity	125 - 12800 (extended to 80 - 25600)
Video Recording	4K UHD (3840 x 2160) at 30p/24p
Viewfinder	Electronic
Image Stabilization	5-axis Hybrid O.I.S.
Connectivity	Wi-Fi
Battery	Li-ion Battery Pack (7.2V, 1025mAh)
Battery Life	Approx. 300 shots
Weight	Approx. 312g with battery and SD Memory Card (0.69 lb) / Approx. 267g without battery and SD Memory Card (0.59 lb)
Shutter Speed	60 - 1/2000 sec (Mechanical Shutter), 1 - 1/16000 sec (Electronic Shutter)
