Panasonic LUMIX GH5 II User Manual

1. Introduction – Names of Parts
29
(1) Stereo microphone ([Sound Rec Level Adj.]: 366)
• Do not block the microphone with a finger. Audio will be difficult to record.
(2) Drive mode dial (Selecting the Drive Mode: 182)
(3) Hot shoe (hot shoe cover) (Removing the Hot Shoe Cover: 305)
• Keep the hot shoe cover out of reach of children to prevent swallowing.
(4) Mode dial (Selecting the Recording Mode: 79)
(5) [WB] (White balance) button (White Balance (WB): 278)
(6) [ISO] (ISO sensitivity) button (ISO Sensitivity: 273)
(7) [ ] (Exposure compensation) button (Exposure Compensation: 269)
(8) Video rec. button (Recording Videos: 325)
(9) [ ] (Photo style) button ([Photo Style]: 285)
(10) Charging light (Charging light Indications: 50)/
NETWORK connection lamp (NETWORK connection lamp: 611)
(11) [ ] (Recording distance reference mark) (Operations on the MF Assist
Screen: 172)
(12) Status indicator (Setting the Clock (When Turning On for the First Time): 70)
(13) Camera on/off switch (Setting the Clock (When Turning On for the First Time):
70)
(14) Mode dial lock button (Selecting the Recording Mode: 79)

Panasonic LUMIX GH5 II Specifications

General

Sensor Type	Live MOS
Megapixels	20.3 MP
Sensor Size	17.3 x 13.0 mm
Image Sensor Format	Four Thirds
Image Processor	Venus Engine
Viewfinder	OLED Live View Finder
Dimensions	138.5 x 98.1 x 87.4 mm
Autofocus System	Contrast Detection
Video Resolution	4K (3840 x 2160)
Viewfinder Resolution	3, 680k-dot
Screen	3.0" Free-Angle Touchscreen LCD
Screen Resolution	1, 840, 000 Dot
Image Stabilization	5-axis in-body image stabilization
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	12 fps
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 Shots
Battery	DMW-BLK22 Lithium-ion
Weight	727 g
