When Moving the Water Purier
Remove water from the main unit with the following steps before moving the product.
z
Stand the main unit while moving. After removing the water, a small amount of water may remain, so
put the main unit in a bag, etc.
1
Disconnect the hose.
Loosen
with hand
Hose
fastening
nut
Hose
z
After disconnecting the hose, attach the
hose fastening nut to the original position
of the bypass selector (loss prevention).
2
Remove the cartridge.
(P. EN19)
3
Put the tip of the hose at a position
lower than the main unit,
and discharge the water
remaining in the hose.
Hose
4
Attach the cartridge and the
cover to the original position.
(P. EN19-EN20)
5
Loosen the nut,
remove the bypass selector,
and remove the water
inside.
Loosen
with hand

When the joint is di󰀩cult to
remove
After tightening the nut rmly with
hand, rotate it together with the bypass
selector. Then it can be removed easily.
z
If it still cannot be removed, use a tool
such as a plier to nip the adaptor, and
remove it.
z
When using a tool such as a plier,
protect the joint with cloth, etc. not to
damage it, and pay attention to the
rotation direction.
Adaptor
EN22
