Installation 4
Attach the bypass selector
Keep all parts that are not used during installation, as they may be needed later if the unit is moved or
the faucet is changed.
Aerator (not used)
y
Do not use the removed aerator.
y
Water faucet to which the bypass selector can be installed without any accessory.
Outside-screwed faucet
1
Remove the nut and adaptor.
Nut
Gasket and Filter
Do not remove the gasket and the lter inside the bypass selector.
If these are removed, return them to the original position.
Make sure foreign matter is not attached to the lter and the gasket
is not inclined.
Gasket
Bypass
selector
Adaptor
(with gasket)
2
Attach the nut and adaptor.
1
2
3
Attach the bypass selector and
tighten the nut until the bypass
selector does not turn.
z
Do not use any tools.
(Doing so may damage the nut.)
z
Make sure the bypass selector is not inclined.
1
2
EN10
