Panasonic MicroClear TK-CS500 - Installation 1; Check the Main Unit and Supplied Accessories

Installation 1
Check the main unit and
supplied accessories
Hose
Faucet
Outlet pipe
Cover
90 °
90 °
Main spout
Cartridge
(Consumables)
(P. EN18-EN20)
Hose
(length: approx. 80 cm)
Main unit
Bypass selector
Overall gure
Items in the package
If any are missing, contact your dealer.

Main unit

Tray

Installation Adaptor
(with 4 screws)

Bushing
(with gasket)

Bypass selector
Supplied Accessories
Batteries are not supplied. Please purchase them from your dealer.
Cartridge life
Indicator
z
The cartridge life is
indicated in 4 levels.
(P. EN18)
Water purication
mark
z
Lights when puried
water is being used.
(P. EN15)
Display
EN6
