Ref. No. Part No. Part Name& Description Pcs Remarks
1 (1) VGM1625 TOP PANEL 1
2 (1) VKC0295 PCB SPACER 4
3 (1) VKF3097 LEG COVER 1
5 (1) VGQ5336 MECHA SUPPORT 1
6 (1) VMT0317 CUSHION 1
7 (1) VJR3 CLAMPER 1
8 (1) VMZ3027 BARRIER (DW) 1
9 (1) VMZ3028 BARRIER 2 (UP) 1
10 (1) VMP6312 REAR PANEL 1
11 (1) VGQ5509 DV HOLDER 1
12 (1) VGQ5345 FAN DAMPER 1
13 (1) VRF0227 FAN MOTOR 1
14 (1) VXA6376 ANGLE (R) UNIT 1
15 (1) VXA6377 ANGLE (L) UNIT 1
16 (1) VYF2678 DOOR U 1
17 (1) VKF3095 BLINDER PANEL 1
18 (1) VMB3333 BLINDER SPRING 1
19 (1) VYP7648 FRONT PANEL UNIT 1
20 (1) LSKA0008 RUBBER LEG 4
21 (1) VMX2983 METAL SPACER 4
22 (1) VGF0869 FAN FILTER 1
23 (1) VEE0H21 WIRE CABLE (6P) 1 P7651-P7602
24 (1) VEE0H20 WIRE CABLE (6P) 1 P3701-P7601
25 (1) VEE0H23 WIRE CABLE (3P) 1 P6001-P1502
26 (1) VEE0K51 WIRE CABLE (2P) 1 P6002-P1501
27 (1) VSQ0687 FERRITE CORE 2
28 (1) VMT0442 SPONGE MAT 2
36 (1) VMC1534 EARTH SPRING 2
42 (1) VWJ1310 FLAT CARD CABLE (32P) 1 P7502-P7901
43 (1) VWJ1309 FLAT CARD CABLE (26P) 1 P7501-P7902
44 (1) VWJ1306 FLAT CARD CABLE (36P) 1 FP3401-FP3201
45 (1) VWJ1307 FLAT CARD CABLE (32P) 1 FP3402-FP3202
46 (1) VWJ1306 FLAT CARD CABLE (36P) 1 FP6201-FP6002
B1 (1) XTB3+8JFZ SCREW 2
B2 (1) XTW3+8M SCREW 4
B3 (1) SNE2129 SCREW 2
B4 (1) XQN16+B4FZ SCREW 1
B5 (1) XTN26+6G SCREW 2
B6 (1) XTN26+8GR SCREW 6
B7 (1) XTV3+35JR SCREW 1
B8 (1) XTV3+6FR SCREW 2
B9 (1) XYE3+EF6FNNC SCREW 3
B10 (1) XTB3+6FFC SCREW 4
B11 (1) XTB3+8GFZ SCREW 5
12.1.2. CHASSIS PARTS SECTION (1)
