Ref. No. Part No. Part Name& Description Pcs Remarks
100 (2) VMA0C20 SUB SHASSIS 1
102 (2) VMG1250 DAMPER 3
105 (2) VEE0H23 WIRE CABLE (3P) 1 P6001-P1502
150 (2) VEG1509 CYLINDER UNIT 1
151 (2) VEM0624 CAPSTAN MOTOR UNIT 1
152 (2) VSC4639 HEAD AMP SHIELD CASE 1
153 (2) VES0914 FLEXIBLE CABLE 1
154 (2) VMA9176 CAPSTAN COVER 1
155 (2) VMA9179 RADON PLATE 1
156 (2) VMA9753 BRUSH ARM STOPPER 1
157 (2) VMB2777 CAPSTAN ADJ. SPRING 1
158 (2) VMD2373 RAIL 1
159 (2) VSC4640 SHIELD CASE 1
160 (2) VSR0114 MODE SWITCH 1
161 (2) VXA5407 CAM GEAR UNIT 1
162 (2) VXA5409 S BOAT UNIT 1
163 (2) VXA5410 T BOAT UNIT 1
164 (2) VXA5417 GEAR BOX (LOADING MOTOR) 1
165 (2) VXA5612 RADON COVER UNIT 1
166 (2) VXL2461 T2 ARM UNIT 1
167 (2) VXL2468 CLEANING ARM UNIT 1
168 (2) VXL2470 S1 ARM UNIT 1
169 (2) VXL2471 T1 ARM UNIT 1
B100 (2) XSN2+3R SCREW 2
B102 (2) XQN16+CJ3 SCREW 2
B103 (2) VHD1297 SCREW 3
B104 (2) XTN2+4F SCREW 2
B105 (2) XYN2+E5FN SCREW 2
B106 (2) XSB2+4 SCREW 2
B150 (2) XQN14+BQ4 SCREW 2
B151 (2) XQN14+B35 SCREW 2
B152 (2) XQN14+B4 SCREW 2
B153 (2) XQN14+B4FZ SCREW 1
B154 (2) VHD0882 SCREW 2
B155 (2) VHD0989 SCREW 2
B156 (2) VHD0878 SCREW 1
B158 (2) XQN14+B15 SCREW 5
B160 (2) XQN14+B15 SCREW 3
B161 (2) VXQ0439 SCREW 3
B162 (2) XQN14+B15 SCREW 1
W150 (2) VMX2027 WASHER 2
12.1.3. CHASSIS PARTS SECTION (2)
