Ref. No. Part No. Part Name& Description Pcs Remarks
200 (3) VDG1342 DRIVE GEAR 2
201 (3) VDG1343 T MAIN RACK 1
202 (3) VDG1344 S MAIN RACK 1
203 (3) VDG1345 SUB RACK 2
204 (3) VDG1346 INTERMEDIATE GEAR 2
205 (3) VDG1347 WORM WHEEL GEAR 1
206 (3) VDG1348 SYNCHRO GEAR 1
207 (3) VMD3556 FRONT GUIDE 1
208 (3) VMD3704 GUARD BLOCK 1
209 (3) VML3423 BLIND LEVER 1
210 (3) VXA6392 CASSETTE HOLDER 1
211 (3) VXA6395 GUARD PANEL 1
212 (3) VXA6396 SIDE PLATE (T) 1
213 (3) VXA6398 OUTER SIDE PLATE (T) 1
214 (3) VXA6400 SIDE PLATE (S) 1
215 (3) VXA6402 OUTER SIDE PLATE (S) 1
216 (3) VDG1264 WORM GEAR 1
217 (3) VMA0C28 MOTOR ANGLE 1
218 (3) VMD3555 THRUST SPINDLE HOLDER 1
219 (3) VXA6743 LOADING MOTOR 1
220 (3) VXA6406 SPINDLE SHAFT (1) 1
221 (3) VXA6480 TOP PLATE 1
250 (3) VDG1445 DRIVE PULLEY 1
251 (3) VDG1031 CENTER PULLEY 1
252 (3) VDG1032 SENSOR GEAR 1
253 (3) VDV0265 TIMING BELT 1
254 (3) VMA9178 PINCH PRESSURE PLATE 1
255 (3) VMA9181 BRAKE ROD SUPPORT (T) 1
256 (3) VMB2776 SPRING 1
257 (3) VSH0067 MIC SWITCH 1
258 (3) VSJ0114 SOLENOID 1
259 (3) VXA5401 BRAKE ROD UNIT 1
260 (3) VXA5408 T3 ROD UNIT 1
261 (3) VXA5411 LED HOLDER UNIT 1
262 (3) VXA6576 COVER PLATE UNIT 1
263 (3) VXL2454 P IDLER ARM UNIT 1
264 (3) VXL2455 FR IDLER ARM UNIT 1
265 (3) VXL2456 TENSION ARM UNIT 1
266 (3) VXL2462 T3 ARM UNIT 1
267 (3) VXL2464 PINCH ARM UNIT 1
268 (3) VXL2466 EJECT ARM UNIT 1
269 (3) VXL2732 PAD ARM UNIT 1
270 (3) VXR0355 SUPPLY REEL TABLE 1
271 (3) VXR0356 TAKE UP REEL TABLE 1
272 (3) VXZ0319 TAKE UP MAIN BRAKE 1
273 (3) VXZ0321 SUPPLY MAIN BRAKE 1
274 (3) VXZ0322 FF BRAKE UNIT 1
275 (3) VXZ0441 REV BRAKE UNIT 1
B200 (3) XTN2+3F SCREW 12
B201 (3) XQN2+A14 SCREW 2
B250 (3) VHD0883 SCREW 4
B251 (3) XQN14+B15 SCREW 2
B252 (3) XQN14+B35 SCREW 1
B253 (3) VHD0884 SCREW 1
B254 (3) XQN14+B35 SCREW 2
B255 (3) VHD0883 SCREW 1
Ref. No. Part No. Part Name& Description Pcs Remarks
W200 (3) VMX0653 WASHER 2
W250 (3) VMX2027 WASHER 1
W251 (3) VMX2394 WASHER 1
W252 (3) VMX2503 WASHER 1
W253 (3) VMX2028 WASHER 1
W254 (3) VMX2504 WASHER 1
W255 (3) VMX2400 WASHER 1
