Chapter 6 Appendix — Technical information
188 - ENGLISH
Mode
Resolution
(Dots)
Scanning freq.
Dot clock
freq.
(MHz)
Format
Plug and play
*1
Horizontal
(kHz)
Vertical
(Hz)
RGB2
DVI-D
HDMI
EDID1 EDID2 EDID3
WSXGA+
1 680 x 1 050 65.3 60.0 146.3 R/D/H ― ― ― ― ―
1 680 x 1 050 54.1 50.0 119.5 R/D/H ― ― ― ― ―
1920 x 1080
1 920 x 1 080 55.6 49.9 141.5 R/D/H ― ― ― ― ―
1 920 x 1 080
*4
66.6 59.9 138.5 R/D/H ― ― ― ― ―
1 920 x 1 080
*6
67.2 60.0 173.0 R ― ― ― ― ―
WUXGA
1 920 x 1 200 61.8 49.9 158.3 R/D/H ― ― ― ― ―
1 920 x 1 200
*4
74.0 60.0 154.0 R/D/H
l
―
l l
*7
l
*7
1 920 x 1 200
*6
74.6 59.9 193.3 R ― ― ― ― ―
*1 Signals with a l in the Plug and play columns are signals described in EDID (extended display identication data) of the projector. If a signal has no
l in the Plug and play columns but has an entry in the Format column, it can be input. For signals without a l in the Plug and play columns, there
are instances when resolution cannot be selected on the computer even though the projector supports them.
*2 Pixel-Repetition signal (dot clock frequency 27.0 MHz) only
*3 When a 1125 (1035)/60i signal was input, it is displayed as a 1125 (1080)/60i signal.
*4 VESA CVT-RB (Reduced Blanking)-compliant
*5 Only for PT-DW750
*6 Samples the pixels in the image processing circuit and projects the image.
*7 Only for PT-DZ780
Note
f The display dot for PT-DZ780 is 1 920 x 1 200, the display dot for PT-DW750 is 1 280 x 800, and the display dot for PT-DX820 is
1 024 x 768. A signal with a different resolution is converted to the number of display dots.
f The “i” at the end of the resolution indicates an interlaced signal.
f When interlaced signals are connected, ickering may occur on the projected image.
f DIGITAL LINK input compatible signal is the same as HDMI input compatible signal.
