[NETWORK] menu
84 - ENGLISH
Settings
■
Name and function of network function parts
(1) (2) (3)
(1) LAN10/100 lamp (yellow)
Lights on when connected to the 100BASE-TX.
(2) <LAN> terminal (10BASE-T/100BASE-TX)
Used to connect the LAN cable here.
(3) LAN LINK/ACT lamp (green)
Lights on when connected.
Flashes when transmitting/receiving data.
