Chapter 2 Getting Started — Removing/attaching the projection lens
ENGLISH - 49
Attaching the projection lens
Attach the projection lens using the following procedure.
Projection lens
Projection lens
Red dot
Fig. 1 Fig. 2
1) Align the mark (red dot) on the projection lens with the mark (red dot) on the projector, and insert it all
the way in. (Fig. 1)
2) Turn the projection lens clockwise to the end. (Fig. 2)
Attention
f Turn the projection lens counterclockwise to conrm that it does not come out.
