ENGLISH - 29
Adjusting adjustable feet
Lift the front of the projector and press the feet lock latch with your nger to adjust the projection angle up and
down. Release your nger to lock the adjustable feet.
For slight adjustment, rotate the adjustable feet.
Rotate the adjustable feet to extend it as shown in the gure, and rotate it in the opposite direction to contract it.
Attention
f Heated air comes out of the air exhaust port while the lamp is lit. Do not touch the air exhaust port directly when you adjust
the adjustable feet.
f If keystone distortion occurs on the projected image, perform [Keystone] from the [Expand] menu. (x page 61)
Adjustable range
Adjustable feet : 40 mm (1-9/16")
Feet lock latch
Feet lock latch
Chapter 2 Getting Started - Setting up
