Manual PC adjust
42
- ENGLISH
Settings
Current mode
Press ▲▼ to select [Current mode].1 )
Press ► or the <ENTER> button to 2 )
enter the next submenu to show
H-sync freq. and V-sync freq. of the
connected computer.
Clamp
Press ▲▼ to select [Clamp].1 )
Press the <ENTER> button to display 2 )
the adjustment dialog box.
Press ◄► to adjust the clamp level.3 )
When the image has dark bars, try this
z
adjustment.
Display area H
Press ▲▼ to select [Display area H].1 )
Press the <ENTER> button to display 2 )
the adjustment dialog box.
Press ◄► to adjust the horizontal area 3 )
displayed by this projector.
Display area V
Press ▲▼ to select [Display area V].1 )
Press the <ENTER> button to display 2 )
the dialog box.
Press ◄► to adjust the vertical area 3 )
displayed by this projector.
Reset
To reset the adjusted data, all adjustments will return
to their previous gures.
Press ▲▼ to select [Reset].1 )
Press the <ENTER> button.2 )
A conrmation box appears and then select [Yes].
z
Mode free
Deletes the values registered in [Store].
Press ▲▼ to select [Mode free].1 )
Press ► or the <ENTER> button to 2 )
enter the next submenu.
Move the highlight to the mode that you want to
z
clear and then press the <ENTER> button.
A conrmation box appears and then select [Yes].
z
Store
Registers the adjusted values in [Store].
Press ▲▼ to select [Store].1 )
Press ► or the <ENTER> button to 2 )
enter the next submenu.
Move the highlight to one of the Modes 1 to 10
z
in which you want to store, and then press the
<ENTER> button.
A conrmation box appears and then select [Yes].
z
