Technical Information
ENGLISH -
95
Appendix
Mode
Display
resolution *
1
(dots)
Scanning
frequency
Dot clock
frequency
(MHz)
Picture quality *
2
PnP *
3
Format
H (kHz) V (Hz)
D-WXGA
1 360 x 768
47.700 60.000 86.670 A
H
56.160 72.000 100.190 A
1 366 x 768
48.360 60.000 86.670 A
46.500 50.000 67.400 A
1 376 x 768 48.360 60.000 86.670 A
1 280 x 768
47.776 59.870 79.500 AA
55.993 69.991 94.964 AA
57.675 72.004 97.817 AA
60.289 74.893 102.250 AA
68.633 84.837 117.500 AA
1 280 x 800
41.200 50.000 68.557 AA
49.702 59.810 83.500 AA
49.572 59.870 83.282 AA
63.980 60.020 108.000 AA
58.289 69.975 98.858 AA
60.044 71.995 102.795 AA
62.790 74.928 106.492 AA
71.553 84.879 122.498 AA
D-SXGA 1 280 x 1 024
31.650 29.800 53.480 A
60.276 58.069 93.067 A
63.980 60.020 108.000 A
D-WXGA+ 1 440 x 900 55.935 59.887 106.500 A
D-WSXGA+ 1 680 x 1 050 65.290 59.954 146.250 A
D-WUXGA 1 920 x 1 200 74.038 59.950 154.000 A
“i” added to the resolution value indicates an interlaced signal.*1 :
Picture quality is indicated by the following symbols.*2 :
AA: Maximum picture quality can be obtained.
A: Signals are converted by the image processing circuit.
Where marked "*3 :
" signals indicates in Plug and Play is compatible with EDID of projector. Unmarked
signals in Plug and Play may also be compliant if input terminals are written in the format list. Where Plug
and Play is unmarked and nothing is written in the format list, difculties in projecting image may occur even
when computer and projector appear to have same resolution.
<COMPUTER 2 IN> terminal does not support Plug and Play.
Note
The number of display dots is 1 280 x 800.
z
A signal with a different resolution will be projected after converting the resolution to match the projector
display.
When interlaced signals are connected, icker may occur on the projected image.
z
DIGITAL LINK and HDMI inputs share the same compatible signal.
z
