Panasonic PT-VZ570

List of compatible signals
The following table species the type of signals compatible with the projectors.
f Symbols that indicate formats are as follows.
g V : VIDEO
g R : RGB
g Y : YC
B
C
R
/YP
B
P
R
g H : HDMI
Mode
Display resolution
(dots)
Scanning frequency
Dot clock
frequency
(MHz)
Format
PnP*
1
H (kHz) V (Hz)
COMPUTER1 /
COMPUTER2
HDMI
NTSC/NTSC4.43/
PAL-M/PAL60
720 x 480i 15.7 59.9 ― V
― ―
PAL/PAL-N/SECAM 720 x 576i 15.6 50.0 ― V
― ―
525i (480i) 720 x 480i 15.7 59.9 13.5 R/Y
― ―
625i (576i) 720 x 576i 15.6 50.0 13.5 R/Y
― ―
525i (480i) 720 (1 440) x 480i
*2
15.7 59.9 27.0 H
― ―
625i (576i) 720 (1 440) x 576i
*2
15.6 50.0 27.0 H
― ―
525p (480p) 720 x 483 31.5 59.9 27.0 R/Y/H
―
l
625p (576p) 720 x 576 31.3 50.0 27.0 R/Y/H
―
l
750 (720) /60p 1 280 x 720 45.0 60.0 74.3 R/Y/H
―
l
750 (720) /50p 1 280 x 720 37.5 50.0 74.3 R/Y/H
―
l
1125 (1080) /60i
*3
1 920 x 1 080i 33.8 60.0 74.3 R/Y/H
―
l
1125 (1080) /50i 1 920 x 1 080i 28.1 50.0 74.3 R/Y/H
―
l
1125 (1080) /24p 1 920 x 1 080 27.0 24.0 74.3 R/Y/H
―
l
1125 (1080) /24sF 1 920 x 1 080i 27.0 48.0 74.3 R/Y/H
― ―
1125 (1080) /25p 1 920 x 1 080 28.1 25.0 74.3 R/Y/H
― ―
1125 (1080) /30p 1 920 x 1 080 33.8 30.0 74.3 R/Y/H
― ―
1125 (1080) /60p 1 920 x 1 080 67.5 60.0 148.5 R/Y/H
―
l
1125 (1080) /50p 1 920 x 1 080 56.3 50.0 148.5 R/Y/H
―
l
640 x 400
640 x 400 31.5 70.1 25.2 R/H
― ―
640 x 400 37.9 85.1 31.5 R/H
― ―
VGA
640 x 480 31.5 59.9 25.2 R/H
l l
640 x 480 35.0 66.7 30.2 R/H
― ―
640 x 480 37.9 72.8 31.5 R/H
l l
640 x 480 37.5 75.0 31.5 R/H
l l
640 x 480 43.3 85.0 36.0 R/H
― ―
SVGA
800 x 600 35.2 56.3 36.0 R/H
l l
800 x 600 37.9 60.3 40.0 R/H
l l
800 x 600 48.1 72.2 50.0 R/H
l l
800 x 600 46.9 75.0 49.5 R/H
l l
800 x 600 53.7 85.1 56.3 R/H
― ―
MAC16 832 x 624 49.7 74.6 57.3 R/H
l l
XGA
1 024 x 768 39.6 50.0 51.9 R/H
― ―
1 024 x 768 48.4 60.0 65.0 R/H
― ―
1 024 x 768 56.5 70.1 75.0 R/H
l l
1 024 x 768 60.0 75.0 78.8 R/H
l l
1 024 x 768 65.5 81.6 86.0 R/H
― ―
1 024 x 768 68.7 85.0 94.5 R/H
― ―
1 024 x 768 81.4 100.0 113.3 R/H
― ―
1152 x 864
1 152 x 864 53.7 60.0 81.6 R/H
― ―
1 152 x 864 67.5 74.9 108.0 R/H
― ―
1 152 x 864 77.1 85.0 119.7 R/H
― ―
MAC21 1 152 x 870 68.7 75.1 100.0 R/H
l l
Chapter 6 Appendix - Technical Information
ENGLISH - 111
