11 Schematic Diagram
TOP PREVIOUS NEXT
(All schematic diagrams may be modified at any time with the development of new technology.)
Notes:
S601 : FF SWITCH
S602 : REW SWITCH
S603 : TAPE/CD STOP SWITCH
S604 : POWER SWITCH
S605 : GEQ SWITCH
S606 : VOLUME DECREASE
SWITCH
S607 : VOLUME INCREASE SWITCH
S621 : CD OPEN/CLOSE SWITCH
S622 : MEMORY SWITCH
S623 : CLOCK/TIMER SWITCH
S624 : TIMER PLAY/REC SWITCH
S625 : CD REC MODE SWITCH
S626 : CD PLAY/PAUSE SWITCH
S627 TUNER BAND SWITCH
S628 TAPE PLAY SWITCH
S629 PAUSE/PLAY SWITCH
S630 : DECK EJECT SWITCH
S701 : RESET SWITCH
S780 OPEN SWITCH
S951 : MODE SWITCH
S952 : LEAF SWITCH
S954 : LEAF SWITCH
● The voltage value and waveforms are the reference voltage of this unit measured by DC
electronic voltmeter (high impedance) and oscilloscope on the basis of chassis. Accordingly,
there may arise some error in voltage values and waveformsdepending upon the internal
impedance of the tester or the measuring unit.
