Panasonic SA-PMX70 - Voltage Measurement Guide; Main (Supply) PCB Voltage Points

57
14 Voltage Measurement
Note:
• Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with
the chassis taken as standard.
Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester.
• Circuit voltage and waveform described herein shall be regarded as reference information when probing defect point because it
may differ from actual measuring value due to difference of Measuring instrument and its measuring condition and product itself.
14.1. MAIN (SUPPLY) P.C.B.
REF NO.
MODE 1 2 4 6 88
POWER ON 5 0 0.98 3.3 0 26
REF NO.
MODE 1 2 4 6 88
POWER ON 5 0 0.96 3.3 0 26
REF NO.
MODE 2 3456
POWER ON 2 0.8 3.3 5.6 3.3
REF NO.
MODE 1 2 345678
POWER ON 5 5 3.3 10000
REF NO.
MODE 1 2 34
POWER ON 3.3 0 1.55 3.3
REF NO.
MODE 1 2 345
POWER ON 12 0 1 3.3 12
SA-PMX70EG MAIN (SUPPLY) P.C.B
.
IC1106
IC1107
IC1101
IC1102
IC1104
IC1110
