Panasonic SA-PMX70 - Page 64

64
VA51 B0ZBZ0000156 VARISTOR 1
SWITCHES
S7201 K0L1BA000158 SW RESET 1
S9203 EVQ21405RJ SW REV 1
S9204 EVQ21405RJ SW PLAY/PAUSE 1
S9205 EVQ21405RJ SW FF 1
S9206 EVQ21405RJ SW HI-Q BT 1
S9207 EVQ21405RJ SW STOP 1
S9208 EVQ21405RJ SW OPEN/CLOSE 1
S9209 EVQ21405RJ SW SELECTOR 1
S9210 EVQ21405RJ SW POWER 1
CONNECTORS
CN51 K1MY12BA0566 12P CONNECTOR 1
CN6100 K1KA07BA0047 7P CONNECTOR 1
CN6101 K1FY104A0015 USB CONNECTOR 1
CN7001 K1MY05BA0539 5P CONNECTOR 1
CN7002 K1MN10B00016 10P CONNECTOR 1
CN9200 K1MY21AA0267 21P CONNECTOR 1
CN9201 K1KB05B00022 5P CONNECTOR 1
CN9202 K1KA06AA0031 6P CONNECTOR 1
P8000 K1KB06B00038 6P CONNECTOR 1
P8001 K1ZZ00001238 OTHER CONNECTORS 1
P9200 K1KA05AA0193 5P CONNECTOR 1
COILS AND INDUC-
TORS
L51 G1CR18JA0020 INDUCTOR 1
L2900 G0A330ZA0045 CHOKE COIL 1
L5704 G0B203G00005 LINE FILTER 1
L5713 G0B922G00002 LINE FILTER 1
L6100 EXC24CE900U FILTER 1
LB51 J0JYC0000656 INDUCTOR 1
LB52 J0JHC0000118 INDUCTOR 1
LB5830 J0JHC0000107 INDUCTOR 1
LB8000 J0JGC0000070 INDUCTOR 1
LB8001 J0JGC0000070 INDUCTOR 1
LCD DISPLAY
DP9300 A2BB00000186 LCD DISPLAY 1
TRANSFORMER
T5701 G4DYZ0000080 SWITCHING TRANS-
FORMER
1
PHOTO COUPLER
PC5721 B3PBA0000579 PHOTO COUPLER 1
PC5761 B3PBA0000579 PHOTO COUPLER 1
TERMINALS
ZJ920 K1KB04B00038 4P CONNECTOR 1
ZJ5701 K4CZ01000027 TERMINAL 1
ZJ5702 K4CZ01000027 TERMINAL 1
ZJ5703 K4CZ01000027 TERMINAL 1
ZJ9200 K1KA04AA0031 4P CONNECTOR 1
FUSE
F1 K5G312Y00007 FUSE 1
REMOTE SENSOR
IR921 B3RAC0000021 REMOTE SENSOR 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
CABLE HOLDER
H2015 K1ZZ00000836 15P CABLE HOLDER 1
THERMISTOR
TH5702 D4CAA5R10001 THERMISTOR 1
JACKS
JK51 K4ZZ02000103 JK FM ANT 1
JK8000 K2HC1YYB0033 JK HEADPHONE 1
P5701 K2AA2B000011 AC INLET 1
CHIP JUMPERS
L54 D0GBR00J0004 0 1/10W 1
LB8002 D0GBR00J0004 0 1/10W 1
LB9203 D0GBR00J0004 0 1/10W 1
W124 ERJ6GEY0R00V 0 1/8W 1
W125 ERJ3GEY0R00V 0 1/10W 1
W20 ERJ3GEY0R00V 0 1/10W 1
W21 ERJ3GEY0R00V 0 1/10W 1
W22 ERJ3GEY0R00V 0 1/10W 1
W23 ERJ3GEY0R00V 0 1/10W 1
W24 ERJ3GEY0R00V 0 1/10W 1
W26 ERJ3GEY0R00V 0 1/10W 1
W27 ERJ6GEY0R00V 0 1/8W 1
RESISTORS
R51 D0GB222JA065 2.2K 1/10W 1
R52 D0GB561JA065 560 1/10W 1
R55 D0GA221JA023 220 1/16W 1
R56 D0GB221JA065 220 1/10W 1
R57 D0GA102JA023 1K 1/16W 1
R59 D0GB222JA065 2.2K 1/10W 1
R60 D0GB331JA065 330 1/10W 1
R64 D0GBR00J0004 0 1/10W 1
R67 D0GBR00J0004 0 1/10W 1
R920 D0GB470JA065 47 1/10W 1
R921 D0GB101JA065 100 1/10W 1
R2905 D1BB4701A074 4.7K 1/10W 1
R2906 D1BB3002A074 30K 1/10W 1
R2907 D1BB3901A074 3.9K 1/10W 1
R2908 D0GB103JA065 10K 1/10W 1
R2909 D0GB102JA065 1K 1/10W 1
R5700 D0GF474JA048 470K 1/4W 1
R5701 D0GF474JA048 470K 1/4W 1
R5702 ERJ1TYJ104U 100K 1W 1
R5703 ERJ1TYJ104U 100K 1W 1
R5704 F1H1H102B047 1000pF 50V 1
R5710 D0GF474JA048 470K 1/4W 1
R5720 D0GD220JA052 22 1/8W 1
R5721 D0GD222JA052 2.2K 1/8W 1
R5722 D0GB562JA065 5.6K 1/10W 1
R5727 ERX2SZJR13P 0.13 2W 1
R5728 D0GB223JA065 22K 1/10W 1
R5732 D0GB102JA065 1K 1/10W 1
R5733 D0GB273JA065 27K 1/10W 1
R5762 D0GB103JA065 10K 1/10W 1
R5763 D0GD103JA052 10K 1/8W 1
R5764 D0GB472JA065 4.7K 1/10W 1
R5766 D0GB333JA065 33K 1/10W 1
R5767 D0GB223JA065 22K 1/10W 1
R5768 D0GB273JA065 27K 1/10W 1
R5801 D0GB101JA065 100 1/10W 1
R5802 D1BB1502A074 15K 1/10W 1
R5804 D1BB8202A074 82K 1/10W 1
R5805 D1BB1002A074 10K 1/10W 1
R5806 D0GB103JA065 10K 1/10W 1
R5808 D0GB472JA065 4.7K 1/10W 1
R5809 D0GD152JA052 1.5K 1/8W 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
