Panasonic SA-PT460 - IC6901(C0 HBB0000057): IC FL Driver

Pin
No.
Terminal Name I/O Function
4 CLK_EN I CLOCK_OUT Enable (Active
High)
5 NC - No Connection
6 NC - No Connection
7 I2C_SCL I/O I2C Clock
8 I2C_ADDR_0 I I2C Clock Slave Address
Selection
9 I2C_ADDR_1 I I2C Clock Slave Address
Selection
10 I2C_ADDR_2 I I2C Clock Slave Address
Selection
11 CP_READY O CP Ready to Receive Next
Instruction (Active High)
12 MODE0 I Operating Voltage Selection
13 MODE1 I Communication Mode Selection
14 NC - No Connection
15 I2C_SDA I/O I2C Data
16 MODE2 I Communication Mode Selection
17 ROSC I Connect via 100 kΩ 1% resistor
to VCC
18 NC - No Connection
19 NC - No Connection
20 NC - No Connection
21 NC - No Connection
22 NC - No Connection
23 NC - No Connection
24 NC - No Connection
25 NC - No Connection
26 NC - No Connection
27 NC - No Connection
28 NC - No Connection
29 NC - No Connection
30 NC - No Connection
31 SYS_CLK_OUT - No Connection
32 NC - No Connection
33 NC - No Connection
34 NC - No Connection
35 NC - No Connection
36 NC - No Connection
37 NC - No Connection
38 nRESET I CP Reset (Active Low)
39 VSS - Supply Voltage, Negative
Terminal
40 VCC - Supply Voltage, Positive
Terminal
23.3. IC6901(C0HBB0000057): IC FL
Driver
Pin
No.
Terminal Name I/O Function
1 LED2 O Led Drive Output
2 LED3 - Led Drive Output
3 LED4 - Led Drive Output
4 LED5 - Led Drive Output
5 OSC I Oscillator Input
6 DOUT - Data Output
7 DIN I Data Input
8 CLK I Clock Input
9 STB I Serial Interface Strobe
10 K1 - Key Data Input 1 (No
Connection)
11 K2 - Key Data Input 2 (No
Connection)
12 GND - GND
13 VCC - Power Supply (+5V)
14 P18 O Segment Output 18
Pin
No.
Terminal Name I/O Function
15 P17 O Segment Output 17
16 P16 O Segment Output 16
17 P15 O Segment Output 15
18 P14 O Segment Output 14
19 P13 O Segment Output 13
20 P12 O Segment Output 12
21 P11 O Segment Output 11
22 P10 O Segment Output 10
23 P9 O Segment Output 9
24 P8 O Segment Output 8
25 P7 O Segment Output 7
26 P6 O Segment Output 6
27 P5 O Segment Output 5
28 P4 O Segment Output 4
29 P3 O Segment Output 3
30 -VP - Voltage Supply
31 P2 O Segment Output 2
32 P1 O Segment Output 1
33 G1 O Grid Segment Output 1
34 G2 O Grid Segment Output 2
35 G3 O Grid Segment Output 3
36 G4 O Grid Segment Output 4
37 G5 O Grid Segment Output5
38 G6 O Grid Segment Output 6
39 G7 O Grid Segment Output7
40 G8 O Grid Segment Output 8
41 G9 O Grid Segment Output 9
42 G10 O Grid Segment Output 10
43 VCC - Voltage Supply (+5V)
44 GND - GND
136
SA-PT460EB / SA-PT460EG
