Ref.
No.
Part No. Part Name & Description Remarks
L3905 G1BYYYC00026 COMMON MODE EMI FILTER [M]
L3906 G1BYYYC00026 COMMON MODE EMI FILTER [M]
L4001 J0JBC0000015 INDUCTOR [M]
L4002 J0JBC0000015 INDUCTOR [M]
L4003 J0JBC0000015 INDUCTOR [M]
L4004 J0JBC0000015 INDUCTOR [M]
L4005 J0JBC0000015 INDUCTOR [M]
L5000 G0A150L00003 CHOKE COIL [M]
L5001 G0B9R5K00003 LINE FILTER [M]
L5002 G0B9R5K00003 LINE FILTER [M]
L5200 G0A150L00003 CHOKE COIL [M]
L5201 G0B9R5K00003 LINE FILTER [M]
L5300 G0A150L00003 CHOKE COIL [M]
L5301 G0B9R5K00003 LINE FILTER [M]
L5400 G0A150L00003 CHOKE COIL [M]
L5401 G0B9R5K00003 LINE FILTER [M]
L5402 G0B9R5K00003 LINE FILTER [M]
L5500 J0JKB0000020 INDUCTOR [M]
L5501 J0JKB0000020 INDUCTOR [M]
L5701 ELF15N035AN LINE FILTER [M]
L5702 G0B932H00001 LINE FILTER [M]
L5703 ELF22V020A LINE FILTER [M]
L6901 J0JBC0000019 INDUCTOR [M]
L6903 J0JBC0000019 INDUCTOR [M]
L6910 J0JBC0000019 INDUCTOR [M]
L6920 J0JBC0000019 INDUCTOR [M]
L8001 G1C100M00049 CHIP INDUCTOR [M]
L8201 G1C100M00049 CHIP INDUCTOR [M]
L8301 G1C100M00049 CHIP INDUCTOR [M]
L8302 G1C100M00049 CHIP INDUCTOR [M]
L8303 G1C100M00049 CHIP INDUCTOR [M]
L8330 G1C100M00049 CHIP INDUCTOR [M]
L8501 G1C100M00049 CHIP INDUCTOR [M]
L8550 G1C100M00049 CHIP INDUCTOR [M]
L9004 G1BYYYC00026 COMMON MODE EMI FILTER [M]
CHIP INDUCTORS
LB3901 J0JHC0000045 INDUCTOR [M]
LB3902 J0JHC0000045 INDUCTOR [M]
LB3903 J0JCC0000042 INDUCTOR [M]
LB3904 J0JCC0000042 INDUCTOR [M]
LB3905 J0JCC0000042 INDUCTOR [M]
LB3906 J0JCC0000042 INDUCTOR [M]
LB3907 J0JHC0000045 INDUCTOR [M]
LB3908 J0JHC0000045 INDUCTOR [M]
LB6401 J0JHC0000034 INDUCTOR [M]
LB6402 J0JHC0000034 INDUCTOR [M]
LB8001 J0JHC0000045 INDUCTOR [M]
LB8011 J0JHC0000045 INDUCTOR [M]
LB8257 ERJ3GEY0R00V 0 1/10W [M]
LB8258 ERJ3GEY0R00V 0 1/10W [M]
LB8259 ERJ3GEY0R00V 0 1/10W [M]
LB8260 ERJ3GEY0R00V 0 1/10W [M]
LB8301 ERJ2GE0R00X 0 1/16W [M]
LB8302 ERJ2GE0R00X 0 1/16W [M]
LB8303 ERJ2GE0R00X 0 1/16W [M]
LB8304 ERJ2GE0R00X 0 1/16W [M]
LB8305 ERJ2GE0R00X 0 1/16W [M]
LB8401 J0JCC0000308 INDUCTOR [M]
LB8421 ERJ2GE0R00X 0 1/16W [M]
LB8422 ERJ2GE0R00X 0 1/16W [M]
LB8423 ERJ2GE0R00X 0 1/16W [M]
LB8424 ERJ2GE0R00X 0 1/16W [M]
LB8425 ERJ2GE0R00X 0 1/16W [M]
LB8426 ERJ2GE0R00X 0 1/16W [M]
LB8427 ERJ2GE0R00X 0 1/16W [M]
LB8428 ERJ2GE0R00X 0 1/16W [M]
LB8429 ERJ2GE0R00X 0 1/16W [M]
LB8430 ERJ2GE0R00X 0 1/16W [M]
LB8431 ERJ2GE0R00X 0 1/16W [M]
LB8432 ERJ2GE0R00X 0 1/16W [M]
LB8530 J0JHC0000045 INDUCTOR [M]
Ref.
No.
Part No. Part Name & Description Remarks
LB8531 ERJ2GE0R00X 0 1/16W [M]
LB8532 J0JDC0000045 INDUCTOR [M]
LB8551 J0JDC0000045 INDUCTOR [M]
LB8561 J0JDC0000045 INDUCTOR [M]
LB8571 J0JDC0000045 INDUCTOR [M]
LB8690 ERJ2GE0R00X 0 1/16W [M]
LB8691 ERJ2GEJ101X 100 1/16W [M]
LB8692 ERJ2GEJ101X 100 1/16W [M]
LB8693 ERJ2GEJ101X 100 1/16W [M]
LB8701 J0JCC0000308 INDUCTOR [M]
LB8702 J0JCC0000308 INDUCTOR [M]
LB8901 J0JCC0000308 INDUCTOR [M]
LB9001 J0JCC0000042 INDUCTOR [M]
LB9002 D0GBR00JA008 0 1/16W [M]
LB9003 D0GBR00JA008 0 1/16W [M]
TRANSFORMERS
T2900 G4D1A0000117 SWITCHING TRANSFORMER [M]
T5701 ETS42BN1A6AD MAIN SWITCHING TRANSFORMER [M]
T5751 ETS19AB256AG BACKUP SWITCHING TRANSFORMER [M]
COMPOMENT COMBINATION
Z6900 B3RAD0000146 SENSOR [M]
TERMINALS
ZJ5400 K4CZ01000027 TERMINAL [M]
ZJ5410 K4CZ01000027 TERMINAL [M]
ZJ5701 K4CZ01000027 TERMINAL [M]
ZJ5702 K4CZ01000027 TERMINAL [M]
ZJ5801 K4CZ01000027 TERMINAL [M]
ZJ5803 K4CZ01000027 TERMINAL [M]
FUSE HOLDERS
ZA5701 K3GE1ZZ00001 FUSE HOLDER [M]
ZA5702 K3GE1ZZ00001 FUSE HOLDER [M]
PSW1 D4FB1R100009 POLY SWITCH [M]
OSCILLATORS
X1701 H0J327200099 CRYSTAL OSCILLATOR [M]
X2001 H2B100500007 CERAMIC RESONATOR [M]
X2700 H0H433400002 CRYSTAL RESONATOR [M]
X5500 H2A6023A0011 CRYSTAL RESONATOR [M]
X5501 H2A7003A0011 CRYSTAL RESONATOR [M]
X8621 H0J270500085 CRYSTAL OSCILLATOR [M]
X9004 H1A4805B0027 48MHZ CRYSTAL OSCILLATOR [M]
DISPLAY TUBE
FL6801 A2BB00000169 FL DISPLAY [M]
FL8101 F1H0J1050018 INDUCTOR [M]
FL8102 F1H0J1050018 INDUCTOR [M]
FL8103 F1H0J1050018 INDUCTOR [M]
FL8104 F1J1E1040022 INDUCTOR [M]
FL8421 F1H0J1050018 INDUCTOR [M]
FUSE
F1 K5D502BNA005 FUSE [M]
FUSE PROTECTOR
FP2901 K5G401A00008 FUSE PROTECTOR [M]
JACKS
JK2001 K2HA2YYA0004 JACK AUX [M]
JK4001 K1FB121B0012 JACK SCART [M]
143
SA-PT460EB / SA-PT460EG
